Specifications
Brand Name :
Sanweihe
Place of Origin :
Qingdao China
Model Number :
SWH-7017
Certification :
CE
MOQ :
1set
Price :
negotiable
Payment Terms :
T/T, L/C
Supply Ability :
10set/Month
Delivery Time :
30 working days
Packaging Details :
Wooden Box Packaging
Forming Function :
Forming, Filling, Seal
Driven Type :
Electric
Material Type :
Solid
Packaging Material :
Film
Dimension(L*W*H) :
4800*1100*1850mm
Keywords :
Wrapping Machine
Color :
Silver Grey
OEM Service :
Available
Paket Type :
Over Wrapping Type
Transport Package :
Wooden Box Packing
Trademark :
SANWEIHE
Origin :
Qingdao China
After-sales Service :
Yes
Warranty :
12 Months
Automatic Grade :
Semi-Automatic
Application :
Cosmetics, Skin Care Products, Tea, Vegetable, Fruit, Seasoning
Customization :
Available | Customized Request
Description

SWH-7017 Automatic Cellophane Over Wrapping Packing Machine for Biscuit


Description about the Packing machine:
Without Tray Automatic Cellophane Over wrapping packing machine is the biscuit packing machine that carriesthe different types of products (e. G. Round, rectangular, square, elliptical, angular) with the different measurements by the help of its transporter and realizes packaging in the envelope form(End-folding type) by wrapping from above and sticking from the edges.

Main Parameters of the wrapping packing machine

Machine measurement(L*W*H): 4800MM*1100MM*1850MM
Weight: 900kg
Total power: 4kw
Feeding voltage: 220V. 50Hz
Power: 3kw
Lengthwise heater power: 600W
Horizontal seal heater power: 6*200W
Engine power: 1.1kw
Engine voltage: 3phase 220V
Packing speed: 10-45bags/min

CE Small Biscuit Packing Machine SWH 7017 Cellophane Packing Machine


Features about the packing machine:
Easy tear strip and beautiful appearance.
Saving packing material and the box space.
Adoptingphoto-electrical eye control system ensures correctly cutting position.
Engine stops in case of overload, High safety function.
Comparing with the manual sealing, could saving 10-15 laborcost
Capacity: 45-50 packet/minute. (capacity varies depending on product type and packing material)
Infeed conveyor and chains are made of stainless steel
All the parts on the machine are stainless steel
All stroke adjustments can be done.
Speed adjust is done by digital device
Max diameter 80mm biscuits can be packed.
Circular, rectangular, square and oval products can be packed.
Single cutting blade.
Photocell hit system of machine is done by pneumatic piston
Cams are hardened after grinding.


CE Small Biscuit Packing Machine SWH 7017 Cellophane Packing Machine


Why choose us:
1. We are manufacture but not trade company
2. We have professional staff who can advise you the suitable packing machine for your specific need
3. Our professional workers will make the perfect packing machine for you
4. Well trained and experienced staff will answer your inquiry timely
5. We provide competitive price and fine quality packing machines
CE Small Biscuit Packing Machine SWH 7017 Cellophane Packing MachineCE Small Biscuit Packing Machine SWH 7017 Cellophane Packing MachineCE Small Biscuit Packing Machine SWH 7017 Cellophane Packing Machine


F.A.Q.:
Q: When you can finish the machine at earliest. Please inform. As we need the machine ASAP.
A: We can finish the machine within 2 weeks(with extra working time) if you need it urgently
Q: What material is used as printed film?
A: The packing film is double sides heat sealable film
Q: Is there any guarantee covering the machine?
A: Our guarantee time for the machine is 1 year
Q: Do you offer after sale service, or else if any part is damaged could you send us
The spare part to replace?
A: Yes we offer after sale service, you can send email or call us when have some
Problem, we will help you to solve the problem freely, we will also send the spare
Parts for replacement, of course the spare parts are not for free
