Specifications
Model Number :
GXPS400
Place of Origin :
Shaanxi, China
Brand Name :
KACISE
Packaging Details :
each unit has individual box and all boxes are packed in standard packages or customers requests available
Supply Ability :
10000 Piece/Pieces per Week negotiable
Price :
$99.00 - $390.00/pieces
Usage :
Level Sensor
Theory :
Resistance Sensor
Output :
Analog SENSOR
Pressure range :
0~1...500mH2O
Port :
Shanghai or other
Description

GXPS400 serial 4-20ma liquid water level sensor

1. Specification of GXPS400 serial 4-20ma liquid water level sensor :
Spec. Numerical value Remark
Pressure range 0~1……500mH2O 1mH2O≈9.81kPa
Overload pressure 1.5times Rated pressure
fracture pressure 3 times rated pressure
Accuracy ±0.25%F.S, ±0.5%F.S, ±1.0%F.S
Stability Typical value: 0.1%F.S Max.: 0.2% F.S/year
Operating Temperature -40°C~85°C or -40 °C ~125 °C
compensation temperature -10°C~70°C
medium compatibility All Caustic Medium Compatible with 1Cr18Ni9Ti and 316L
electrical properties 2 line 3 line
Output signal 4~20mA 0~5V 0~10V
Power supplies 10~30Vdc 80~30Vdc/ac 11~30Vdc/ac Vdc/ac
load resistance (U-10)/0.02( ) more than 100k
insulation more than 100M @50V
Electrical Connections waterproof fixed cable + Two rectangle circle+Sealing Rings+seal gum+ Pure glue protection grade : IP68
pressure interface G1/4,input type
response time 10ms
Electric strength 500Vac@1 second
Graduate Certificate Programs certificate of explosion-proof, CE
electromagnetic compatibility electromagnetic radiation EN50081-1/-2, electromagnetic susceptibilty: EN50082-2
lightning protection air conduction resistance 8000V,case, cable conduction

2. Feature of GXPS400 serial 4-20ma liquid water level sensor :

Diffused-Silicon oil filled core

All kinds of structure to satisfy different users

Easy to use with submersible measuring

Multiple pressure range and signal output

Non-polar 2 wire system current output

Can be used in lightning protection products

Reinforcing rib of liquid cable

Intrinsically safe explosion proof, Isolation explosion proof, CE4 - 20ma Liquid Water Level Sensor / Fuel Level Sensor Waterproof

3. Application of GXPS400 serial 4-20ma liquid water level sensor :

Deep well level measuring

Hydrologic measurement for river, lake, sea

Sewage treatment

Cloudy level measuring

Fluid reservoir level measuring

Water-saving irrigation

Circulating liquid consumption monitoring

Diversion works
