Compact Shear Beam Compression Load Cell / Alloy Steel Strain Gauge Weight Sensor
Compact Shear Beam Compression Load Cell / Alloy Steel Strain Gauge Weight Sensor
Compact Shear Beam Compression Load Cell / Alloy Steel Strain Gauge Weight Sensor
Compact Shear Beam Compression Load Cell / Alloy Steel Strain Gauge Weight Sensor
Specifications
Brand Name :
KACISE
Model Number :
KLD-301
Certification :
CE
Place of Origin :
China
MOQ :
1 Piece/Pieces
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000 Piece/Pieces per Month
Delivery Time :
7 Working days
Packaging Details :
Carton / Wooden box
Capacity :
0.11, 0.22, 0.55, 1.1, 1.76, 2.2, 4.4t
Accuracy :
C3
Hysteresis :
0.017%F.S
Non-linearity :
0.017%F.S
Zero balance :
±2%F.S.
Material :
Alloy Steel
Description

Compact Shear Beam Compression Load Cell Strain Gauge Of Alloy Steel

Introduction

The cantilever beam weighing sensor, also known as a shear beam weighing sensor, typically features a cuboid shape with the strain area positioned in the center. Equipped with two fixed holes at the tail end and a pressure attachment at the front end, it is designed to bear substantial weight. Typically arranged in groups of three or four sensors, their signals are collectively processed and transmitted to the measuring instrument through a signal and conditioning device to display the measured values.

The sensor's elastomer adopts a shear or bending cantilever beam structure with one end fixed, providing versatility for bearing and measuring various tensile and compression forces. Key features include dustproof sealing, a broad measurement range, high precision, stable and reliable performance, as well as straightforward installation and use.

This sensor is applicable to electronic weighing, various industrial automation measurement and control systems, with applications including automotive press fit, automated assembly, 3CS product testing, new energy product assembly, medical testing, robotics, mold assembly, and other industrial testing and control systems. It is characterized by a low profile, small deflection, and is made of stainless steel for enhanced durability.

Features

Made of stainless steel, strong stability;

Used in various automated stamping applications, IP68 protection;

Applications

Mainly used for packing scales, hopper scale and industrial weighing sytem.

Technical Specifications

Capacity 0.11, 0.22, 0.55, 1.1, 1.76, 2.2, 4.4t
Accuracy C3
Sensitivity 1.94±0.1%mV/V
Zero balance ±2%F.S.
Non-linearity 0.017%F.S
Hysteresis 0.017%F.S
Repeatability 0.017%F.S
Creep (30min) 0.0166%F.S
Temp.effect on output 0.014%F.S/10℃
Temp.effect on zero 0.0125%F.S/10℃
Input impedance 390±3Ω
Output impedance 350±5Ω
Insulation ≥5000MΩ/100VDC
Recommended excitation 5V
Maximum excitation 15V
Compensated temp range -10~40℃
Operation temp range -30~70℃
Safe overload 150%F.S
Ultimate overload 300%F.S
Cable size Φ5.4x1500mm
Weight approx.

0.9kg (0.55~1.76t)

1.6kg (2.2t)

2.2kg (4.4t)
Material Stainless steel
IP class IP68

Dimensions and Connection

Compact Shear Beam Compression Load Cell / Alloy Steel Strain Gauge Weight SensorCompact Shear Beam Compression Load Cell / Alloy Steel Strain Gauge Weight Sensor

Mounting dimension

Cap (t) A B C D E F G H J K M
0.11~1.76 133.4 76.2 25.4 15.4 30.7 30.2 57.7 14.2 13 20.6 M12
2.2 136.7 76.2 25.4 18.4 36.8 36.6 55.6 16.6 13 12.5 M12
4.4 171.5 95.3 38.1 21.4 43.9 432.9 73.8 22.9 20.5 22.2 M20
