External level gauges supporting 2-wire or 4-wire output are used for industrial horizontal tank level monitoring
Product Overview
External level gauges, which support either 2-wire or 4-wire output, play a crucial role in industrial horizontal tank level monitoring. These gauges are crafted with high-quality materials and advanced technological features. The 2-wire or 4-wire output options provide flexibility in system integration and data transmission. They offer precise and reliable measurements, ensuring accurate assessment of the liquid levels within horizontal tanks. With their durable construction, they can endure the rigors of industrial settings, including temperature fluctuations, vibrations, and corrosive environments. Their user-friendly design makes installation and operation straightforward, facilitating seamless incorporation into industrial processes and enhancing overall operational efficiency and safety.
Technical Parameters
Non-Intrusive Level Gauge | Two-wire | Four-wire |
Measuring Range | 3m, 5m, 10m, 15m, 20m, 30m, 50m | |
Display Resolution | 1mm | |
Short-Term Repetition | 1mm | |
Error | ±1‰FS, ±2‰FS, ±5‰FS | |
Temperature Range | -45℃~+100℃ | |
Accuracy | 1℃ | |
Output | 4~20mA (Maximum load 500Ω), HART,Modbus | |
Power Supply | DC24V (22V~36V) | DC24V (18V~30V) |
Power | < 1 W | < 1 W |
Communication | RS-485,Infrared, HART,Modbus | |
Relay Alarm Output | AC 250V 5A, DC 30V 5A | |
Ambient Temperature Host | -40℃~+80℃ | |
Ambient Temperature Display | -20℃~+70℃ | |
Ambient Temperature Sensor | -50℃~+100℃ | |
Ambient humidity | (0%~95%)RH | |
Explosion-proof | ExdⅡCT6 | |
Protection | IP65, IP67 | |
Display | 128×64 LCD | |
Blind Area | < 30mm Under ideal working conditions | |
Electrical Interface | M20X1.5 (F), 1/2 NPT (F) | |
Cable Length | 5m, optional | |
Host size / weight | 158mmx122mmx148mm, 2kg, base hole dia M5 |
Level Gauge Dimension
Host Dimension
Sensor Probe Dimension
Installation diagram
horizontal tank
vertical tank
Ball Tank
Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, etc. which assure our products are conform to the international standards.
We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.
Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.
1. Q: What information need to be provided to choose the suitable model External level gauges supporting 2-wire or 4-wire output are used for industrial horizontal tank level monitoring?
A: Please provide us:Range, medium, temperature, tank type (horizontal tank, vertical tank, spherical tank, etc.)so we can choose model and quote for you quickly.
2. Q: Are you a trade company or a manufacturer?
A: We are an ISO approved manufacturer specialized in level and flow measuring instruments.
OEM & ODM service are available. Welcome to visit us.
3. Q: What is your MOQ?
A: To start our cooperation, sample order is acceptable.
4. Q: What is your delivery date?
A: The delivery date is about 3-15 working days after receipt of payment.
5. Q: What is your payment terms?
A: We support T/T, PayPal and Trade Assurance.
For mass production order, it is 30% deposit in advance and 70% balance before shipment.
6. Q: What is Trade Assurance payment method:
A: It’s a free service which can protect your orders from payment to delivery.
And we now have USD104,000.00 of caution money to assure your orders.
7. Q: Do you have a warranty?
A: Yes, we have the warranty of 12 months.
