SF-503 PTFE Polytetrafluoroethylene Powder Low RR For Thread Seal Tape
SF-503 PTFE Polytetrafluoroethylene Powder Low RR For Thread Seal Tape
SF-503 PTFE Polytetrafluoroethylene Powder Low RR For Thread Seal Tape
SF-503 PTFE Polytetrafluoroethylene Powder Low RR For Thread Seal Tape
SF-503 PTFE Polytetrafluoroethylene Powder Low RR For Thread Seal Tape
SF-503 PTFE Polytetrafluoroethylene Powder Low RR For Thread Seal Tape
Specifications
Brand Name :
Sinof
Model Number :
SF-503
Place of Origin :
China
Price :
To be negotiated
Packaging Details :
woven plastic bag with inner polyethylene bag
Delivery Time :
To be negotiated
Payment Terms :
L/C, T/T
Max Reduction Ratio :
400:1
Description

PTFE Fine Powder SF-503with Low RR for Thread Seal Tape

Grades and Technical Properties

Item SF-501 SF-503 SF-5046CF SF-504 SF-504X SF-504S
Bulk Density, g/L 475±100
Tensile Strength, MPa≥ 24
Elongation, % 480-550 300 250 300
Moisture Content, %≤ 0.03
Standard Specific Gravity ≥ 2.200 2.150-2.200 2.160-2.200 2.150-2.200 2.120-2.150 2.150-2.220
Average Particle Size, μm 400-575
Maximum Reduction Ratio 400:1
Extrusion Pressure, Mpa 20.0-40.0(400:1) 30.0-50.0(400:1) 20.0-35.0(400:1) 30.0-45.0(400:1) 45.0-60.0(400:1) 25.0-45.0(400:1)
Processing Method Paste Extrusion

Item SF-506H SF-503S SF-5048 SF-5041 SF-506 SF-5049
Bulk Density, g/L 475±100
Tensile Strength, MPa≥ 24 25 24 25
Elongation, % 300
Moisture Content, %≤ 0.03
Standard Specific Gravity ≥ 2.120-2.150 2.160-2.190 2.160-2.220 2.145-2.175 2.135-2.170 2.140-2.200
Average Particle Size, μm 400-575
Maximum Reduction Ratio 400:1 2500:1 100:1 1000:1
Extrusion Pressure, Mpa 45.0-60.0(400:1) 25.0-45.0(400:1) 45.0-70.0(1700:1) 50.0-75.0(1700:1) 10.0-20.0(100:1) 20.0-40.0(400:1)
Processing Method Paste Extrusion

Application:

SF-501: Designed for low-density seal tape and short fiber.

SF-503: Designed for high-density seal tape, elastic band and fiber.

SF-5046C: Designed for thick wall tube and electric wire with excellent clarity property.

SF-504: Designed for elastic band, membrane, cable wrapping film.

SF-504X: Designed for long fiber.

SF-504S: Designed for membrane.

SF-506H: Designed for membrane.

SF-503S: Designed for thick wall tube and thin rod with low reduction ratios.

SF-5048: Designed for thin tube, thin wall tube and wire, cable with medium and high reduction ratios. Excellent electrical performance, high thermal stability property.

SF-5041: Designed for thin wall tube and electric wire with medium and high reduction ratios. Excellent fiber forming property, wide processing range.

SF-506: Designed for membrane.

SF-5049: Designed for forming tubes with excellent transparency and pressure resistance. High thermal stability, superior stress crack resistance, low permeability and excellent clarity.

Packaging, Storage and Transportation:

1. The product is packed in two layers of plastic bags in a hard bucket with a net content of 20kg per barrel.

2. The products shall be transported as non-dangerous chemical. During transportation, prevent from humidity, intense vibration and package damage.

3. Products should be stored in a clean, cool and dry warehouse to prevent the mixing of dust, moisture and other impurities.
