ASTM D4894 PTFE Molding Powder SF-81 YELLOW
ASTM D4894 PTFE Molding Powder SF-81 YELLOW
Specifications
Brand Name :
Sinof
Model Number :
SF-81 YELLOW
Place of Origin :
China
Appearance :
White powder
Chemical Resistance :
Excellent
Corrosion Resistance :
Excellent
Density :
2.2 g/cm3
Electrical Properties :
Excellent
Flammability :
Non-flammable
Melting Point :
327°C
Molecular Formula :
C2F4
Molecular Weight :
200-400
Oxidation Resistance :
Excellent
Product Name :
PTFE Compound
Solubility :
Insoluble in water
Tensile Strength :
High
Thermal Conductivity :
Low
Viscosity :
Low
Description

PTFE Molding Powder (SF-81 YELLOW)

Technical Properties

Mechanical Properties Units Test Method Free Flow NFF
Specific Gravity g/cm³ ASTM D4894 2.15±0.02 2.15±0.02
Tensile strength MPa ASTM D4894 ≥27.5 ≥27.5
Elongation at break % ASTM D4894 ≥290 ≥290
Bulk Density g/L ASTM D4894 ≥820 /
Hardness Shore D NEEDLE 56-50 56-50
Diametric Shrinkage % INTERNAL 2.0±0.5 2.0±0.5
Flow Sec/120g INTERNAL ≤5 /
Average Particle Size μm ASTM D4894 550±100 /
Recommended Molding Pressure 300-350kg/cm2
Max Sintering Temp. 370-375℃

Attention:

This product is a fluoroplastic material. Normal precautions observed with fluoroplastics should be followed.

Packaging, Storage and Transportation:

1. The product is packed in two layers of plastic bags in a hard bucket with a net content of 25kg per barrel.

2. The products shall be transported as non-dangerous chemical. During transportation, prevent from humidity, intense vibration and package damage.

3. Products should be stored in a clean, cool and dry warehouse to prevent the mixing of dust, moisture and other impurities.
