Specifications
Brand Name :
Lead Laser
Model Number :
LD-CUT-200
Certification :
CE, FDA, ISO9001
Place of Origin :
China
MOQ :
1 Set
Price :
Price can be negotiated
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
200 Set Per Year
Delivery Time :
30 Working Days
Packaging Details :
Wooden Case at 234x234x100cm
Laser Wavelength :
1064nm
Laser Power :
200W
Laser Medium :
Nd: YAG
Pulse Frequency :
1-500HZ
Working Area :
1200X1200X100mm
Continuous Working Time :
24 Hours
Guarantee Period :
2 Years
Technical Support :
Whole Life
Description

LD-CUT-200 200W Laser Metal Marking Machine And Cutting Machine Applied For Tools, Hardware And Other Metal Materials

Brief and Function:

LD-CUT-200W laser cutting machine adopts the pulsed Nd: YAG solid-state laser, working medium is neodymium-doped yttrium aluminum garnet crystal, pump source is Xe lamp. The output laser wavelength is 1,064µm, it’s infrared light without visible. Laser host adopted the metal resonator imported from Germany, used the premium grade YAG laser crystal as the work ing substance, equipped with the advanced optical system and high-quality beam focusing system, conducted the specially designed laser route, YAG laser to achieve a high power density, low-divergence angle of output, so that it can complete the cut function.

This machine is the special equipment for metal cutting and drilling, Incision is smooth, the vertical degree is good, adapted to be cutting and drilling for stainless steel, carbon steel, copper, aluminum, molybdenum and other metal materials, also have the punch and simple marking function. Numerical control programming, graphics and text can be processed at arbitrary planar. Stable and reliable machine operation, good processing quality, high efficiency, simple operation and easy maintenance.

Application:

It is widely used in machinery manufacturing, such as machine tools, transportation machinery, metallurgical machinery, electronics, electrical appliances, electrical manufacturing, automobile manufacturing, telecommunications, broadcasting and information industry, aviation, aerospace industry, petroleum, chemical industry, stone, plastic, paper and rubber products industry, etc.

Technological Parameter:

Laser wavelength 1064nm
Laser medium Nd: YAG
Laser power 200W
Pulse Frequency 1-500Hz
Working current 100A-450A
Pulse Width 0-20MS
Beam divergence ≤3mrad
Power instability ≤2.5％
Cutting speed 1000mm/min(1mm thick stainless steel plate)
Cutting Area X×Y×Z =1200×1200mm×100mm
Dimension of worktable 1500mm×1500mm or 2000mm X 2000mm (optional)
Cutting dimension precision ±0.2mm
Positional accuracy ±0.02mm/300mm
Repeat positioning accuracy ±0.02mm
Cutting thickness stainless steel plate≤4.5mm, carbon steel plate≤5.0mm, brass≤1.5mm, aluminum≤2mm
Maximum input power 16KW
Continuous working Time 24h
Minimum kerf width ≤0.1mm
Focus Lens focal lengths 100mm
