LD-EMK-CO2-90 90W Desk Style CO2 Laser Marking Machine For PET, PVC And Other Nonmetal Materials
CO2 laser engraving and marking machine is a type of gas laser machine with wavelength 10.6um. CO2 is filled in the sealed glass tube as the medium to radiate laser. Given high voltage, CO2 gas in the tube generates laser and after amplification laser beam with higher energy comes out. Galvanometer scanning system can change the path of the laser beams to guarantee high-speed automatic marking finished.
CO2 laser engraving and marking machine is applied to most kinds of non-metallic materials and part kinds of metallic meterials, like acrylic, wood, leather, fabric, bamboo products, glass, architectural ceramics, rubber, etc. Widely used in pharmaceutical packaging, food packaging, beverage packaging, plastics, textiles, handicrafts, electronic components, communications, watches, glasses, printing and other industries. It can be used to marking, engraving, hollowing and cutting varoius non-metallic materials such as texts, symbols, graphics, images, barcodes, serial numbers,etc.
Application and materials
Industrials: spirits, tobacco, medication, foodstuff & drink, individual nursed materials, electron wares, cards, arts and crafts, building materials and leather etc.
Materials: paper, plastics, pellicle, tin foil, wood, glass, PVC, ABS and EP etc.
Advantage:
Technical Data:
Max. Laser Power | 90W |
Laser Wavelength | 1064nm |
Repeat Fequency | 20kHZ |
Marking Range | 100x100mm |
Marking Contents | Characters, symbol, logo, bar code, two-dimension code, graphics, image, full automatism serial number, batch number, real time clock, automatism date of manufacture and encrypt number at will |
Marking Speed | 0-70M/Minute (optional) |
Min. Line Width | 0.1mm |
Marking Depth | 3mm |
Repeat Accuracy | ±0.01mm |
Min. Character Size | 0.3mm-60mm (optional) |
Marking Lines | 1-10 |
Style of Characters | Chinese, English, Figures and Logo |
Image Direction | 0o-360o (optional) |
Scanner Direction | 0o-90o (optional) |
Information Memory | Absoluteness |
Character Height | Absoluteness within marking range |
Laser Deflexion System | High Speed Scanner |
Control System: | Standard computer, true color LCD, Windows XP editor interface, operation in English, can editor figure, character and images. |
Input Port | Input interface of production inductor, non normal working input of on-line production |
Output Port | Alarm signal output for laser fault and environment exceed standard |
Working Method | Using equipped with customer’s product line or customized at the customer’s option |
Input Power | 700W |
Electrical Source | 220V/single-phase/60Hz/5A |
Cooling System | Air cooling |
Machine Dimensions | 350X550X320mm |
Wuhan Lead Laser Co., Ltd. is a high-tech corporation located in the Optics Valley of China, Wuhan. It’s a professional manufacturer for the various laser machine developed and produced more than 10 years. High Speed Flying CO2 laser marking machine is our self-developed and manufactured new on-line flying laser date code machine equipment, it can make the high speed marking on the mass products on line perfectly. It’s the best capability laser spray code machine at present in the domestic market.
