Inert Gas Fire Prevention System 100L Red IG 100 Fire Suppression System
Inert Gas Fire Prevention System 100L Red IG 100 Fire Suppression System
Inert Gas Fire Prevention System 100L Red IG 100 Fire Suppression System
Inert Gas Fire Prevention System 100L Red IG 100 Fire Suppression System
Inert Gas Fire Prevention System 100L Red IG 100 Fire Suppression System
Inert Gas Fire Prevention System 100L Red IG 100 Fire Suppression System
Specifications
Brand Name :
Rongxiao
Model Number :
QMD20/90 QMD20/82 QMD20/80 QMD15/90 QMD15/80 QMD15/70
Certification :
CAL,CMA,CNAS,,CCC
Place of Origin :
Guangzhou City, Guangdong Province, China
MOQ :
1set
Price :
Negotiation
Payment Terms :
L/C, D/P, Western Union, T/T, Credit card
Supply Ability :
18000 sets per week
Delivery Time :
10 days, subject to quantity negotiation
Packaging Details :
Plywood outer box with bubble bag or paper
Product name :
fm200 fire suppression system,6mm Fire detection tube
Color :
Red
Capacity :
100L
Filling pressure :
4.2MPa
Discharge time :
≤10s
Item :
FM 200 system design,fire suppression systems fm200,50kg co2 fire extinguisher
Starting mode :
Electrical manual,Automatic
Application :
widely usde for combustible and flammable liquid,Commercial Kitchens,Fire Fighting Emergency Rescue
Install type :
DIY easy install
Description

Brief introduction of IG100 gas fire extinguishing agent

IG100 gas fire extinguishing agent is recognized as a "green" environmental protection gas fire extinguishing agent which can replace halon fire extinguishing agent in the world, and has been widely used in the world. It is composed of nitrogen medium (see the table below for its composition and quality requirements), and its ozone depletion potential value ODP=0 (no damage to the atmospheric ozone layer) and greenhouse effect value DWG=0 (no greenhouse effect). It is colorless, odorless, non-polluting, non-corrosive and has good insulation performance. After the fire extinguishing agent is sprayed into the protected area, the oxygen concentration decreases and the carbon dioxide concentration in the protected area increases. The moderate increase of carbon dioxide concentration can accelerate people's breathing frequency, improve their oxygen absorption function, and maintain their oxygen absorption needs to some extent. IG100 fire extinguishing agent is stored and sprayed in gaseous form. When it is released to the high-temperature protection zone where a fire occurs, it will not decompose, produce toxic decomposition products, form dense fog or cause unclear vision, so as to ensure that people can clearly see the emergency exit when they escape. Therefore, IG100 gas fire extinguishing agent is non-toxic and harmless to human body, and it is a safe and environment-friendly gas fire extinguishing agent, which is suitable for places where people often work.

IG100 gas composition and quality requirements

Main components Nitrogen(N2)
Proportion 100%
Purity requirement (volume ratio) ≥99.9%
Water content requirement (mass ratio) ≤4×10-4%
Oxygen content requirement (mass ratio) ≤3×10-4%

Fire extinguishing principle of IG100 fire extinguishing agent

As we all know, a substance needs to have three elements to maintain combustion: ① it should be combustible, ② it needs an accelerant (oxygen), and ③ it needs to reach a certain temperature. Usually, the oxygen concentration in the protection zone is about 21%. If the oxygen concentration in the protection zone is reduced and the oxygen content in the air is reduced, the reduction of oxygen content in combustible materials can reduce the heat generation rate during combustion, and when the heat generation rate is reduced below the heat loss rate, the combustion will stop. Experiments show that when the oxygen concentration in the environment drops below 12.5%, most combustible materials will stop burning. When a fire occurs, IG100 gas can be sprayed into the protection zone, so that the oxygen in it can be reduced to below 12.5%, and the combustion products can be stopped, thus putting out the fire.

System technical parameters and composition

1. System technical parameters

Executive standard GB 25972-2010
System working pressure(20℃时,MPa) 15 20
Volume of fire extinguishing agent bottle group(L) 70 80 90 80 82 90
System injection time(s) ≤60 ≤60
Filling quantity of extinguishing agent(kg) 12.47 14.25 16.04 17.48 17.92 19.67
System service temperature(℃) 0～+50 0～+50
Minimum fire extinguishing design concentration 37.5% 37.5%
Safe design concentration of manned workplace ≤43% ≤43%

2. System composition The IG100 gas fire extinguishing equipment provided by our company adopts total flooding fire extinguishing method, which can usually be divided into the following two forms:

(1) Unit independent IG100 fire extinguishing system (Figure 1): A set of IG100 fire extinguishing agent storage device corresponds to a set of pipe network system to protect a protected area. (2) Combined distribution type IG100 fire extinguishing system (Figure 2): A common IG100 fire extinguishing agent storage device corresponds to several casing network systems to protect multiple protection zones.

Inert Gas Fire Prevention System 100L Red IG 100 Fire Suppression System

1. Fire extinguishing agent bottle bracket. 2. Fire extinguishing agent bottle group. 3. Connect the pipes. 4. Fire extinguishing agent circulation pipeline one-way valve. 5. Safety release device. 6. Collecting pipe. 7. Control the trachea. 8. Signal feedback device. 9. Pressure reducing device. 10. Select the valve. 11. Drive the one-way valve of the gas flow pipeline. 12. Low leakage and high sealing valve. 13. Drive the gas bottle assembly bracket. 14. Nitrogen drives the gas cylinder assembly. 15. Fully submerged nozzle.

System outline installation dimensions

Inert Gas Fire Prevention System 100L Red IG 100 Fire Suppression System

Figure 3 System Outline Diagram

Specifications L1 L2 L3 L4 H1 H2
QMD15/70 340 630+340n 570+340n 305 1050 1850

QMD15/80

QMD20/80

QMD20/82

 340 630+340n 570+340n 305 1300 2030
QMD15/90 340 630+340n 570+340n 305 1500 2100
QMD20/90 340 630+340n 570+340n 305 1500 2180

Overall dimensions and performance parameters of fire extinguishing agent bottle group

Specifications volume(L) Filling Weight (kg) Total weight(kg) gross(mm) outside diameter(mm) Outlet connection thread Filling pressure at 20℃(MPa)
DMP70/15 70 12.47 103 1600 279 M30×1.5 15
DMP80/15 80 14.25 115 1800 279
DMP90/15 90 16.04 120 1975 279

Specifications volume(L) Filling Weight (kg) Total weight(kg) gross(mm) outside diameter(mm) Outlet connection thread Filling pressure at 20℃(MPa)
DMP80/20 80 17.48 143 1830 279 M30×1.5 20
DMP82/20 82 17.92 146 1860 279
DMP90/20 90 19.67 157 2000 279

Company introduction

Guangzhou Rongan Fire Protection Equipment Co., Ltd. is a professional manufacturer of fire protection facilities integrating R&D, production, design and sales services. The company has experts from the national fire protection industry standards committee and a group of professional technical service teams with more than ten years of experience in the fire protection industry, and will spare no effort to provide you with the most intimate and professional comprehensive technical solutions for fire protection engineering products. "Rongxiao" series products produced by the company have passed the national compulsory product certification and the national fixed fire extinguishing system inspection center, with reliable quality and stable performance, and the factory has passed the ISO9001 quality system certification.

Frequently asked questions

Q1: Are you a manufacturer or a trading company? A1: We are manufacturers.

Q2: How long is the delivery time? A2:10 days, which can be negotiated according to the quantity.

Q3: How to deal with the fault? A3: During the warranty period, we will provide you with a remote emergency plan during working hours. During the free maintenance period, the company will replace spare parts or complete machines that have failed due to defects or quality problems free of charge.
