Specifications
Brand Name :
Fiberplan
Model Number :
GYXTW
Certification :
ISO 9001; TÜV certificate ; CE ; ROSH
Place of Origin :
China
MOQ :
1Km
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000Km per month
Delivery Time :
5-8 work days
Packaging Details :
Wooden Drum
Application :
Telecommunication,Aerial,Telecom,Network
Fiber type :
single mode & multi mode
Color :
Black or Customized
Jacket material :
PE,LSZH,PVC,TPU,LSZH OR PVC
Operating temperature :
-40~+75
Name :
GYXTW
Structure :
Central Loose Tube
Length :
Standard Length Of Cable Shall Be 2 Km. Other Cable Length Is Also Availabler
Water Blocking :
Dry water blocking
Description

Outdoor Armored Singlemode GYXTW G652D Outdoor Single Mode Fiber Optic Cable

Description

The cable utilizes high modulus plastic tubes housing the fibers, reinforced with a water-resistant compound.

Corrugated steel tape, sealed with water-blocking material, creates a compact and waterproof configuration.

Parallel steel wires provide additional reinforcement along the tape. Finally, a protective polyethylene (PE) s-

heath ensures overall environmental resilience.

Application

This specification outlines the basic prerequisites for a Central Loose Tube Outdoor Cable intended for aerial

or duct installations.

Characteristics

1 Temperature-Resilient Construction: Ensures consistent performance across diverse environmental temper-

atures with robust mechanical resilience.

2 Fiber Protection: Provides critical shielding for fibers through a hydrolysis-resistant, high-strength loose tube

and specialized filling compound.

3 Combined Strength and Flexibility: Enhanced by dual parallel steel wires, offering a balance between crush

resistance and flexibility, bolstering its tensile strength for long-term reliability.

4 Effortless Installation: Engineered with a compact, lightweight design for easy and adaptable installations in

various applications, ensuring user-friendly deployment.

Cable construction details

Number of fiber 0~24core
Loose tube material PBT
diameter Ф2.2(outer/inner)
Tube-filling Tube filling compound
Steel wire size 0.8mm
Number 2
Outer sheath material PE,HDPE,LDPE
diameter 7±0.3mm

Fiber color

Number of fiber 8

cores per tube

 1 2 3 4 5 6
Blue Orange Green Brown Grey White
7 8 9 10 11 12
Red Black Yellow Violet Pink Aqua
Color 13~24 will be marked with a black tracer.For black color no need marked black tracer, will use nature color instead.

Cable Mechanical characteristic

core Cable diameter weight
1~24 8.0mm±0.3mm 65kg/km±10kg
Temperature range -40 ~ +70 -----
Min Bending Radius (mm) Long term 10D
Min Bending
Radius (mm)		 Short term 20D
Min allowable
Tensile Strength (N)		 Long term 1200
Min allowable
Tensile Strength (N)		 Short term 1500
Operation
temperature (℃)		 -40 ~ +70
Installation
temperature (℃)		 -20 ~ +60
Storage temprature (℃) -40 ~ +70

Fiber characteristic

Fiber style Unit SM
G652		 SM
G652D		 MM
50/125		 MM
62.5/125		 MM
OM3-300
condition nm 1310/1550 1310/1550 850/1300 850/1300 850/1300
attenuation dB/km ≤ ≤ ≤ ≤3.0/1.0 ≤3.0/1.0
0.36/0.23 0.34/0.22 3.0/1.0 ---- ----
Dispresion 1550nm Ps/(nm*km) ---- ≤18 ---- ---- Dispresion
1625nm Ps/(nm*km) ---- ≤22 ---- ---- 　
Bandwith 850nm MHZ.KM ---- ---- ≧400 ≧160 Bandwith
1300nm MHZ.KM ---- ---- ≧800 ≧500 　
Zero dispersion wavelength nm 1300-1324 ≧1302,
≤1322		 ---- ---- ≧ 1295,
≤1320
Zero dispresion slope nm ≤0.092 ≤0.091 ---- ---- ----
PMD Maximum Individual Fibr 　 ≤0.2 ≤0.2 ---- ---- ≤0.11
PMD Design Link Value Ps(nm2*km) ≤0.12 ≤0.08 ---- ---- ----
Fibre cutoff wavelength λc nm ≧ 1180,
≤1330		 ≧1180,
≤1330		 ---- ---- ----
Cable sutoff
wavelength λcc		 nm ≤1260 ≤1260 ---- ---- ----
MFD 1310nm um 9.2±0.4 9.2±0.4 ---- ---- ----
1550nm um 10.4±0.8 10.4±0.8 ---- ---- ----
Numerical
Aperture(NA)		 　 ---- ---- 0.200±0.015 0.275±0.
015		 0.200±0
.015
Step(mean of bidirectional
measurement)		 dB ≤0.05 ≤0.05 ≤0.10 ≤0.10 ≤0.10
Irregularities over fiber
length and point		 dB ≤0.05 ≤0.05 ≤0.10 ≤0.10 ≤0.10
Dicontinuity
Difference backscatter
coefficient		 dB/km ≤0.05 ≤0.03 ≤0.08 ≤0.10 ≤0.08
Attenuation uniformity dB/km ≤0.01 ≤0.01 　 　 　
Core dimater um 　 　 50±0.6 62.5±2.1 50±0.8
Cladding diameter um 125.0±0.2 125.0±0.2 125.0±0.2 125.0±0.2 125.0±0.2
Cladding non-circularity % ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0
Coating diameter um 242±5 242±5 242±5 242±5 242±5
Coating/chaffinch
concentrically error		 um ≤12.0 ≤12.0 ≤12.0 ≤12.0 ≤12.0
Coating non circularity % ≤6.0 ≤6.0 ≤6.0 ≤6.0 ≤6.0
Core/cladding conentricity error um ≤0.6 ≤0.6 ≤1.5 ≤1.5 ≤1.5
Curl(radius) um ≤4 ≤4 ---- ---- ----
