High Efficiency Rubber Vacuum Gripper For Rough Application Conditions ATC B20
High Efficiency Rubber Vacuum Gripper For Rough Application Conditions ATC B20
High Efficiency Rubber Vacuum Gripper For Rough Application Conditions ATC B20
High Efficiency Rubber Vacuum Gripper For Rough Application Conditions ATC B20
High Efficiency Rubber Vacuum Gripper For Rough Application Conditions ATC B20
High Efficiency Rubber Vacuum Gripper For Rough Application Conditions ATC B20
High Efficiency Rubber Vacuum Gripper For Rough Application Conditions ATC B20
High Efficiency Rubber Vacuum Gripper For Rough Application Conditions ATC B20
Specifications
Brand Name :
AMILA
Model Number :
ATC B20
Place of Origin :
CHINA
MOQ :
Negotiatable
Price :
Negotiatable
Payment Terms :
L/C, T/T
Supply Ability :
Negotiatable
Delivery Time :
Depending on the order quantity
Packaging Details :
Carton package/Wooden cases
SIZE :
258x130 to 1410x130
Seal Element :
B20 Rubber Grippers
Highlight :
Built-in vacuum generator
Model No. :
ATC B20
Feature :
High Efficiency
Description

Foam Vacuum Gripper Large Area Built-in Rubber Suction Cups ATC B20

1. Technical Data:

Type Number of suction holes Air consumption Maximum suction capacity Maximum vacuum Suction force Weight
【I/min】 【I/min】 【%】 【N】 【kg】
ATC-SVK 258 5R36 B20 34 180 1050 60 113 3
ATC-SVK 278 5R36 B20 35 180 1050 60 116 3.3
ATC-SVK 294 5R36 B20 39 180 1050 60 130 3.6
ATC-SVK 420 5R36 B20 55 180 1050 60 180 4.5
ATC-SVK 508 5R36 B20 69 270 1190 60 230 4.9
ATC-SVK 618 5R36 B20 84 270 1350 60 270 5.4
ATC-SVK 816 5R36 B20 110 360 1600 60 360 8
ATC-SVK 978 5R36 B20 130 450 2700 60 430 9.1
ATC-SVK 1212 5R36 B20 165 540 2940 60 540 10.6
ATC-SVK 1410 5R36 B20 194 630 3180 60 630 12
ATC-SW 258 5R36 B20 34 180 820 60 87 2.9
ATC-SW 278 5R36 B20 35 180 860 60 89 3.2
ATC-SW 294 5R36 B20 39 180 900 60 100 3.5
ATC-SW 420 5R36 B20 55 180 1050 60 140 4.4
ATC-SW 508 5R36 B20 69 270 1190 60 175 4.8
ATC-SW 618 5R36 B20 84 270 1350 60 210 5.3
ATC-SW 816 5R36 B20 110 360 1600 60 280 7.9
ATC-SW 978 5R36 B20 130 450 2700 60 330 9
ATC-SW 1212 5R36 B20 165 540 2940 60 420 10.5
ATC-SW 1410 5R36 B20 193 630 3180 60 490 11.9

2. Deaign data:
High Efficiency Rubber Vacuum Gripper For Rough Application Conditions ATC B20
Type Dimensions(mm)
B H H1 H2 H3 L L2 Y1
ATC-SVK 258 5R36 B20 130 50 38 9.7 7.7 258 242 98
ATC-SVK 278 5R36 B20 130 50 38 9.7 7.7 278 262 98
ATC-SVK 294 5R36 B20 130 50 38 9.7 7.7 294 278 98
ATC-SVK 420 5R36 B20 130 50 38 9.7 7.7 420 404 98
ATC-SVK 508 5R36 B20 130 50 38 9.7 7.7 508 492 98
ATC-SVK 618 5R36 B20 130 50 38 9.7 7.7 618 602 98
ATC-SVK 816 5R36 B20 130 50 38 9.7 7.7 816 800 98
ATC-SVK 978 5R36 B20 130 50 38 9.7 7.7 978 962 98
ATC-SVK 1212 5R36 B20 130 50 38 9.7 7.7 1212 1196 98
ATC-SVK 1410 5R36 B20 130 50 38 9.7 7.7 1410 1394 98
ATC-SW 258 5R36 B20 130 50 38 9.7 7.7 258 242 98
ATC-SW 278 5R36 B20 130 50 38 9.7 7.7 278 262 98
ATC-SW 294 5R36 B20 130 50 38 9.7 7.7 294 278 98
ATC-SW 420 5R36 B20 130 50 38 9.7 7.7 420 404 98
ATC-SW 508 5R36 B20 130 50 38 9.7 7.7 508 492 98
ATC-SW 618 5R36 B20 130 50 38 9.7 7.7 618 602 98
ATC-SW 816 5R36 B20 130 50 38 9.7 7.7 816 800 98
ATC-SW 978 5R36 B20 130 50 38 9.7 7.7 978 962 98
ATC-SW 1212 5R36 B20 130 50 38 9.7 7.7 1212 1196 98
ATC-SW 1410 5R36 B20 130 50 38 9.7 7.7 1410 1394 98

ATC&ATD.pdf
