Optic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black
Optic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black
Optic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black
Optic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black
Optic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black
Optic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black
Optic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black
Optic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black
Specifications
Brand Name :
Weiroct
Model Number :
SC APC Patchcord
Certification :
ISO 9001/CE/ROHS
Place of Origin :
Hubei, China
MOQ :
50pcs
Price :
USD
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
1000pcs/day
Delivery Time :
5~20 DAYS
Packaging Details :
250pcs/Carton
Product Type :
FTTH Drop Cable Patchcord
Quality Control :
100% Test Before Delivery
Fiber Type :
Singlemode
Inserion Loss :
<0.2dB
Operate Temperature :
-40℃~75℃
Jacket Material :
LSZH
Fiber Count :
Simplex
Application :
FTTH System
Wavelength :
850nm/1310nm/1550nm
Cable Diameter :
4.8-5mm
Description
Optic Fiber Patch cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black
Product Description:
The SC connector was the first small form factor connector on the market. The use of a high performance 2.5mm ferrule gives the connector extremely high performance. SC connector comprises of a polymer body and a ceramic ferrule/sring/crimp barrel assembly plus a crimp over sleeve and rubber boot. These connectors are suitable for 900um and 2mm cables. The connector is precision made and manufactured to demanding specifications. The combination of a ceramic ferrule and a precision polymer housing provides consistent long-term mechanical and optical performance.

Optical Feature:


Low insertion loss, high return loss
Good in repeatability and exchangeability
High temperature stability
Excellent endface geometry
ISO9001:2008, ROHS
Various fiber cable length, jacket color, connector type and label, etc.
All products undergo 100% strict quality inspection before shipment.

Content Testing Condition (dB)
SM MM
APC UPC PC
Optical Performance IL(dB) 1310/1550nm LD Light 0.2 0.2 0.2 0.2
RL(dB) 1310/1550nm LD Light 65 55 50 35

Environment

Performance

 High Temperature +85℃,168H 0.2
Temperature cycle -40~+75℃,21cycle,168H 0.2
Humidity thermal(Fixed) 5℃,95%R.H.,168H 0.2
Humidity thermal cycle 10~+65℃,95%R.H.,21 cycle,168H 0.2
Mechanical Performance Vibration 10~55Hz,1.5mm(p-p) 0.1
Bending 0.9kgf,-90°~+90°,100cycle 0.1
Torsion 2.5kgf,10times/min,±180°,200times 0.1n
Anti-tension 90N,10min 0.1
Dropping 1.5 height, 8 times 0.2
Repeat 10 Times inserts 0.1
Durability >1000times 0.2

Optic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH BlackOptic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH BlackOptic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH BlackOptic Fiber Patch Cord SM SX G657A2 SC/UPC-SC/UPC 2*3MM LSZH Black
