G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
Specifications
Brand Name :
WRC
Model Number :
FTTH fiber cable G657A LSZH fiber optical drop cable messenger cable
Certification :
ISO9001
Place of Origin :
China
MOQ :
1KM
Price :
USD0.43-USD15/Km
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50000 Kilometre / Month
Delivery Time :
5~20 DAYS
Packaging Details :
2KM/Roll/Carton Box
Jacket :
LSZH/PVC/HDPE
Outer Sheath Color :
Orange
Fiber Type :
OM3
Application :
Telecommunication
Strength Member :
Aramid Yarn/Metal wire
Core :
4/6/8/12
Product Name :
FTTH fiber cable G657A LSZH fiber optical drop cable messenger cable
Description

FTTH fiber cable G657A LSZH fiber optical drop cable messenger cable

Specifications

1. 1 -288 Core
2. LSZH jacket drop cable
3. G657 FTTH fiber optical cable
4. Self-support drop cable

G657A G.652D 1 2 4Core Ftth Drop Cable Outdoor Optical Fiber

Self-supporting butterfly drop cable (GJYXFCH/GJYXFDCH) is made from the disc into the optical fiber cable outer in add a stout rope suspension wire.

1. Thick wire

2. Not metal or metal strengthening element

3. Fiber core or optical fiber belt (G657, A2) (1-4 core)

4. Low smoke zero halogen resistance (LSZH) sheath

Fiber Characteristic:

Cable code

Fiber

Count

Cable diameter

mm

Cable

weight

Kg/km

Tensilse

Strength

Long/Short term

N

Crush

Resistance

Long/Short term

N

Bedning

Radius

Dynamic/Static

mm
GJXFH-1 1 (2.0±0.2)×(3.0±0.2) 8 30/60 300/1000 15/30
GJXFH-2 2 (2.0±0.2)×(3.0±0.2) 8.5 30/60 300/1000 15/30
GJXFH-4 4 (2.0±0.2)×(3.0±0.2) 10 30/60 300/1000 15/30
GJXH-1 1 (2.0±0.2)×(3.0±0.2) 9 30/60 300/1000 15/30
GJXH-2 2 (2.0±0.2)×(3.0±0.2) 9.5 30/60 300/1000 15/30
GJXH-4 4 (2.0±0.2)×(3.0±0.2) 10 30/60 300/1000 15/30
Technical data:
strength member
material
Galvanized steel wire/FRP/KFRP
diameter
2*(0.5~0.8)mm
Self support Messenger wire
material
Galvanized steel wire
diameter
1.0mm
Outer sheath
material
LSZH
diameter
1.8±0.2mm
Cable size (Height * width)
2.0(±0.1) mm × 5.2(±0.2)mm
Cable sheath thickness
Max. 0.8mm/Min. 0.4mm
Messenger sheath thickness
0.5~0.7mm
Cable weight
1~2core
18.2KG
4-6 core
18.5KG
8~24core
54KG


G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
More products
Indoor cable
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
Outdoor cable
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
G657A FTTH Messenger Fiber Optic Cable With LSZH Jacket
FAQ

1. Are you the real manufacturer?
Us. We are the real manufacturer with 15 year’s history.

2. What’s the MOQ?
Us. The MOQ of Fiber Optic cable is 1km.

3. What’s delivery time?
Us. The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.

4. How to Store the Optical Fiber Cable Properly?
Us. Store the drum indoor before using, the drum should place sideways not on the end.

5. Can you supply customized products and logo?
Yes. We supply OEM service. You can send us your drawing.
