Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
Specifications
Applicable Industries :
Ice Making Machine
Condition :
New
Place of Origin :
China
Ice Shape :
ICE BLOCK
Voltage :
380V/3P/50HZ
Power :
65KW/ton
Dimension(L*W*H) :
L11890mm*W2160mm*H2745mm
Weight :
16800 KG
Warranty :
1.5 years
Key Selling Points :
Remote Monitoring
Ice storage capacity :
30TONS
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1.5 years
Core Components :
Pressure vessel, Motor, Pump, Gearbox, Engine, PLC
Application :
Industrial
Material :
Stainless steel and Aluminum alloy
Compressor :
Germany Bitzer
Cooling way :
Water Cooled Condenser
Refrigerant :
R404a/R22a
Usage :
Seafood Transportation
Power supply :
3P/220V-440V/50Hz/60Hz(Optional)
Control system :
Siemens Program Control System
Feature :
Fast Making
Ice size :
10/15/20/25/50/100kg
Refrigerate Components :
Famous International Brands
Packaging Details :
CONTAINER
Port :
shanghai port
Supply Ability :
50 Set/Sets per Month
Price :
$60,000.00/sets >=1 sets
MOQ :
1pc
Description

COMPANY INTRODUCTION

Focusun factory is located in Shanghai city, production and R&D team is located in Taizhou city, Jiangsu province, with more than 35,000 square meters of standardized modern plant. Our main products include all kinds of ice maker, cold storage, vacuum cooler, snow making machine, mine cooling system, etc.

There must be one product suits your business! Professional sales teams combined with excellent working experience production. Bring products from factory directly to you, cost of different marketing channels saving.

Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine


Focusun BLOCK ICE MAKER INTRODUCTION

Focusun ™ Block Ice Machine adopts the world's most advanced block ice making technology and we are proud to be one of the global leading manufacturers of this innovative cooling solution.

We have a wide range of block ice solutions; you can choose either from a Brine or Direct System of cooling depending on your requirement. Our Brine and Direct Systems of block ice plants can also be containerized to allow for a mobile ice manufacturing process, better space planning or convenient relocation. We save you from the trouble of assembling and disassembling.

Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine

Main Features

- Adopt dense special formula aluminum alloy as evaporator, improve heat exchange effect, real rust prevention and corrosion protection, guarantee service life
- The water contact between the water tank and the water is made of aluminium plate, and the material is not rusty
- Thermal defluorination. In the inlet water temperature of 20 degrees, water temperature, the ice doffing time is 23 minutes, fast and energy saving
- The overall modular equipment makes transportation, moving, field installation very simple
- According to different ice size, we are tailor-made for customers for each direct refrigeration block ice machine
- The direct ice block ice machine can be made into a container type container, and the ice making capacity of 20 feet container is 6 tons / day, and the maximum ice making capacity of the 40 foot container is 20 tons / day
- Customers can choose the automatic ice transfer device which can be used connected to the power supply. Ice can be automatically transported to the outside of the machine, greatly improving the efficiency of artificial ice moving.



Our FOCUSUN New block ice machine give the Best Solution:
The Ice machine's ice thawing and ice doffing are fully-automatic, don't need manual work. This machine only use water value to add water, no any chemical during production, so the ice is edible.
1. It's direct freezeing type
2. Need fewer time, freezing 15kg block just needs 4 hours
3. Aluminium plate never corrode, food grade and sanitary
4. Don't need large room, hoist, noise, dirty pool, never
5. Compact system, Easy to transport ,easy to operate, easy to get enough more blocks
Below are some pictures of Brine system block ice machine and Direct System block ice machine, for your reference.

Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine

If you are considering to purchase an block ice machine, or you are just want to know information about the block ice machine and prepare your business for future, please feel free to contact Focusun sales team.

We are looking forward to give our best supports.
We are also welcome your visit to FOCUSUN CHINA FACTORY to have face-to-face meeting with our engineering team.

After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.

Fresh food edible Stainless steel 20Ton per day direct evaporation block ice machine
