Specifications
Applicable Industries :
Food & Beverage Factory, Farms
Condition :
New
Place of Origin :
Shanghai, China
Brand Name :
FOCUSUN
Ice Shape :
ICE BLOCK
Voltage :
380V/220V
Warranty :
15 months, 15 months
Key Selling Points :
High Productivity
Ice storage capacity :
Other
Machinery Test Report :
Not Available
Video outgoing-inspection :
Provided
Warranty of core components :
1.5 years
Core Components :
PLC, Compressor
Daily capacity :
50tons/day
Cooling mode :
water cooling
Power supply :
380V/3P/50Hz/220V/3P/60Hz
Compressor supplier :
Germany Bitzer/ Taiwan Hanbell
Valve supplier :
Danmark Danfoss
Evaporator material :
Stainless steel
Per block ice weight :
50kilos
Refrigerant :
R22 or R404A
Usage :
fish cooling/seafood transportation
After Warranty Service :
Video technical support, Online support
Local Service Location :
None
Showroom Location :
None
Certification :
CE
Marketing Type :
Hot Product 2019
Packaging Details :
1. Standard wooden case for main frame. 2. Completely ice machine contain: machine, brine tank, ice block cans, cover, cooling tower, water pump, water pipes and water pipe fittings. 3. Machine come into use, customer only need prepare power for the machin
Port :
SHANGHAI
Supply Ability :
35 Set/Sets per Month
Price :
$50,000.00 - $100,000.00/units
MOQ :
1pc
Description

General Introduction about Focusun :

Focusun is the refrigeration equipment manufacturer leading the peer industry. We mainly produce flake ice machine, tube ice machine, block ice machine, plate ice machine, cube ice machine, water cooling equipment, concrete cooling system, dynamic ice storage system, and all kinds of low temperature ice storage room.

Quick Introduction about the block ice plant, Model: FIB-500S

Type: Brine system block ice plant
Power Supply: 220v/415V/50Hz/3P
Model No.: FIB-500S
Capacity: 50000KG/DAY
Cooling way: Water-cooling
Compressor: Bitzer
Refrigerant: R22/R404A
Dimension:

See layout design
Brief introduction The production of block ice is a batch operation and, once emptied, the cans are refilled with water and replaced in the brine tank for a further freezing period. Whatever the capacity of the ice-maker for block ice production, a continuous labour force is required to manage all operations, particularly ice harvesting and handling. All process could be completed within the container.

Note: We have block ice plants of small, medium, large capacity, which ranges from 1t to 100t or more. All the specifications

can be personalized according to your requirments.

If you need more technical parameters, you http://www.block-ice-plant.com/
may visit our website to get more details about our ice machines :

http://www.block-ice-plant.com/

The main advantages of Focusun block ice:

Comparing to other forms of ice, block ice is specially designed for tropical and hot areas, for middle east, African, etc. Stroage, handling and transport can all be simplified especially for remote areas transportation. Moreove, under the same condition, block ice has the longest storage period.

Brine refrigeration block ice machine technical parameter

Model Capacity Refrigerant Electricity consumption Installment power Operating weight Dimension
-- Ton/D -- Kw Kw Kg mm
FIB-50B 5 R22/R404A 21.14 25 Unit L1400×W1000×H1250
Evaporator L4800×W1000×H2250
Cooling tower 1380×H2170
FIB-100B 10 R22/R404A 40.69 50 Unit:1680 L1800×W1000×H1450
Evaporator:2860×2 L4800×W1000×H2250
Cooling tower:670 2000×H2410
FIB-150B 15 R22/R404A 60.60 75 Unit:2160 L2000×W1200×H1600
Evaporator:2860×3 L4800×W1000×H2250
Cooling tower:1120 2175×H2565
FIB-200B 20 R22/R404A 88.50 105 Unit:2896 L2400×W1600×H1800
Evaporator:2860×4 L4800×W1000×H2250
Cooling tower:1300 2650×H2645
FIB-250B 25 R22/R404A 98.80 120 Unit:3260 L3200×W1800×H2200
Evaporator:2860×5 L4800×W1000×H2250
Cooling tower:1630 3050×H2780
FIB-300B 30 R22/R404A 120.30 150 Unit:3500 L3000×W2000×H2200
Evaporator:2860×6 L4800×W1000×H2250
Cooling tower:2730 3300×H2785
Standard condition: Dry ball temperature is 33 °C and water inlet temperature is 20°C.
