Provided Video Outgoing-Inspection 1ton 3ton 5ton 10ton Ice Maker Machine for Clear Ice

Specifications

Applicable Industries :

Hotels, Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Home Use, Retail, Food Shop, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company

Condition :

New

Place of Origin :

Jiangsu, China

Ice Shape :

tube ice

Voltage :

220v~440v

Power :

4.74kw

Dimension(L*W*H) :

1400x800x1800(mm)

Weight :

890 KG

Warranty :

1 Year

Key Selling Points :

Competitive Price

Ice storage capacity :

Other

Machinery Test Report :

Provided

Video outgoing-inspection :

Provided

Warranty of core components :

1 Year

Core Components :

PLC, compressor, condenser, evaporator

Compressor brand :

Bitzer, Danfos

Application :

Industrial, Fresh-keeping

Product name :

Ice Maker

Keyword :

Tube Ice Making Machine

Refrigerant :

R404a/R22

Cooling way :

Air Cooling Water Cooling

Control system :

PLC+Touch Screen

Tube ice diameter :

21mm/28mm/34mm

Power supply :

3P/220V-440V/50Hz/60Hz(Optional)

After-sales Service Provided 1 :

Online Support

After-sales Service Provided 2 :

Field Maintenance

Price :

$10,600.00/sets 1-4 sets

MOQ :

1pc

Description

Product Description

1. Tube ice is formed in a vertical shell-and-tube vessel by water passing down inside the tubes which are cooled by the
circulation of refrigerant on the outer surface.
2. As the ice falls from the tubes it is cut by the rotating ice cutter to a desired size. The ice tubes are about 50 mm in length
and 21, 28, 34mm three options in external diameter.
3. When the ice reaches the desired thickness, water will stop flowing automatically. The refrigerant is removed to a surge drum
and hot gas is circulated around the tubes causing the ice tubes to melt and slide down.

Tube Ice Dimensions

Tube ice is a kind of hollow cylindrical ice with external diameter ø21、ø28、ø34mm and length 25～42mm. The hole diameter is usually ø5～10mm and it can be adjusted according to ice making time.

Product Configuration

Bitzer compressor

Simens PLC

Danfoss Controller

Detailed Images

Machine Parts

Name: Evaporator module

The evaporator and its accessories are installed on a steel frame which forms the evaporator module. When transporting , place the evaporator horizontally and stand it upright when installing .

Main Features

A complete unit with all equipment assembled in a steel frame except its cooling tower for water-cooling or air fan for air-cooling. It's suitable for container shipment, easy to ship, move and install. Right after connecting to an electric and water source, the machine can be put into use

Machine Parts

Name: Ice generator

The main part of the tube ice machine is the ice generator, a vertical shell-and-tube vessel surrounded by a water tank. Special water distributors on top of each tube control an even,spiral supply of water down the inside of the tubes. Expess water is collected in a tank beneath the ice generator and pumped back up to the tank at the top .

Ice Application

Tube ice is widely used in hotels, restaurants, bars, flight kitchens, catering, concrete cooling, chemical industry processing, food production processing, fishing industry and a variety of laboratory and medical applications.

Product Specifications

Model	Daily Capacity	Refrigerant	Electricity Consumption	Install Power	Operating Weight
FIT-10	1T	R22/R404A	4.74kw	6kw	890kg
FIT-30	3T	R22/R404A	11.01kw	13.5kw	1250kg
FIT-50	5T	R22/R404A	16.03kw	20kw	1650kg
FIT-100	10T	R22/R404A	34.95kw	45kw	4526kg

Smart APP

Foucusun Direct Refrigeration Block Ice Machine is equipped with the smart APP,which can be an unique design in the Ice Making Machine.It will be much more convenient to operate the machine.

Focusun Inte-star Control System APP includes the following features：

1.Check all running data and working status of the machine anytime and anywhere.

2.Realize remote on/off operation and improve work efficiency.

3.Realize one-click report when find features,24hours fast response.

4.Regular maintenance warning to protect your machine.

Packing & Delivery

Packaging
Size	1800 (L) * 1000 (W) * 1450 (D)
Weight	3000kg
Packaging Details	The normal package is wooden box(Size: LWH). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.

FAQ

1.How to choose suitable block ice machine？
Please tell us you need what daily capacity of machine and the weight of per block and your area dimensioin.

2. how can we guarantee quality?
CE,ISO, BV & SGS strictly inspected as per customer requested. Every products pass through good performance test before delivery.

3.why choose us？
Over 80 years of experience of engineering and manufacturing in refrigeration industry; Cost-effective Machines: German Technology Own 18 patented refrigeration technologies.

4. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,,Western Union;
Language Spoken:English,Chinese,Spanish,Portuguese,German,Arabic,French

About Focusun

FOCUSUN---Cooling Technical Master Since 1929, Germany

Focusun is a pioneer in ice cooling techlonogy and manufacture worldwide. We mainly design and manufacture tube ice machine, block ice machine, flake ice machine, cube ice machine, plate ice machine, water chiller, concrete cooling system, automatic ice storage system, dynamic ice storage system and all kinds of cold rooms. Over a decade, we have provided quality service to more than 16,000 professional clients in 150 countries around the world. Now we have a factory of 36,000 square meter in Taizhou, Jiangsu province, China.

Focusun (shanghai) Refrigeration Equipment is founded in 2008. In fact, our activity in refrigeration technology is dated back to 2002. In 2012. Focusun(Shanghai) is authorized by Kulinder Incorporation(Germany) to deal with all business, D&M and promotion in China and granted the full right to use the brand of Kulinder, Focusun, pictures and the copyright of design &manufacture in China.
