Three 400mm Height Coil Winding Machine , PLC Control Automatic Wire Winder
Three 400mm Height Coil Winding Machine , PLC Control Automatic Wire Winder
Specifications
Brand Name :
Zhutang
Model Number :
ZPX400-3
Certification :
Main parts with CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
100 sets per year
Delivery Time :
30-35 days
Packaging Details :
Seaworthy wooden case packing
Colour :
optional
Wire material :
flat and round wire
Flat wire :
5x12mm
Round wire :
0.3-4.0 mm
Motor power :
7.5kw
Transverse :
400mm
Rotating diameter :
800mm
Quality warranty :
12 months
Description

Three 400mm Height Coil Winding Machine , PLC Control Automatic Wire Winder

Description

Three 400mm Height Coil Winding Machine , PLC Control Automatic Wire Winder ZPX400-3 is a high efficient coil winding machine. The coil winding machine can be used to wind three same coils with max height 400mm. The winding machine is provided with foot pedal, counter, colored touch screen, servo motor, and so on. The foot pedal can be used to control the machine and switch the rotating direction, the counter can counter the number of turns and exact reversible winding counting. Coloured touch screen is very intuition for inputting parameters. Servo motor driven wire guide guarantees the excellent start- stop behaviour, which assures high quality laying wire. 7.5kw motor provides strong pulling force. Control system is based on PLC, which make the machine achieve different behaviour.

Main Features

  • Slow starting
  • Smooth running
  • Full function
  • Used widely
  • Wire guide is driven by AC servo motor
  • Simple operation, accuracy and reliability
  • High automation

Technical Parameters

Typical standard specifications of ZPX400-3 are shown below, however these can be easily modified as requested.

  • Center height from the floor: 900mm
  • Rotating diameter max. 800mm
  • Winding shaft size 40x40x1500mm, this is optional
  • Round wire diameter 0.3-4.0mm
  • Max. each finished coil height 400mm
  • Max number of finished coil 3 pcs
  • Number of insulation decoiler 1 pc
  • Main motor power 7.5kw
  • Rotating speed 0-160 rpm
  • Control system PLC
  • Minimum spread pitch 0.01mm
  • Counting range 0-9999.99
