Ultra Thin High Brightness Curtain LED Display RGB , Indoor Full Color LED Screen 6mm
Ultra Thin High Brightness Curtain LED Display RGB , Indoor Full Color LED Screen 6mm
Specifications
Brand Name :
Onumen
Model Number :
F-P6
Certification :
CE/ROHS/FCC/TUV
Place of Origin :
Shenzhen,China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T 50% deposit,the balance should be paid before shipment
Supply Ability :
1000sqm per month
Delivery Time :
25 working days after received your payment
Packaging Details :
Packed in flightcase
Pixel Pitch :
6mm
Module Size :
192mmx192mm
Brand :
Onumen
Brightness(cd/m2) :
2000
Max.Power Consumption(W/m2) :
300
LED SPEC :
SMD3528
Working Voltage :
DC24V
Drive Mode :
Scan 1/16
Description

Ultra Thin High Brightness Curtain LED Display RGB , Indoor Full Color LED Screen 6mm

Feature:


1. Wide application: it can be used for any rental application of stage show: such as main screen, side

screen, floor screen, arc screen stage design etc.


2. Easy and Fast for installation and dismantling: without any tools, it takes only 10 seconds to assembly,

hanging, pile up and fix installation available.


3. Module structure design:modules can be installed and dismantled from front side,Easy and quick

independently dismantle and replace

4. High structure performance: Separate design of power supply and screen body ensures that the

screen is cool&quiet


5. Both indoor and outdoor series are compatible, outdoor SMD with IP65 weatherproof level, so it can be

used normally in rainy days.

Specifications:

Model No. Slim 6
Pixel Pitch 6mm
Module Size 192x192mm
Module Resolution(pixels) 32*32
Panel Size 768mm×2112mm, be customized as per customer's request. Max can be 768*6144m
Panel Resolution(pixels) 128X352
Pixel Configuration(RGB) 1R1G1B
Pixel Density(pixels/m2) 27777
Brightness(cd/m2) 2000
Best Viewing Distance(m) >6m
Max.Power Consumption(W/m2) 300
Waterproof Level Indoor IP43/Indoor IP54
Wavelength R 625±5nm, G 525±5nm B 470±5nm
LED SPEC SMD3528
Viewing Angle 110°(H)/110°(V)
Operating Temperature –20~50°C
Video Frame Rate(Hz) 30-120HZ
Display Refresh Rate(Hz) ≥4000HZ
Grey Level(colors) 16.7million
MTBF ≥50000 hours
Lifespan ≥100000Hours
Working Voltage DC24V
Drive Mode Scan 1/16
Graphics Card DVI Graphics card
Video Signal RF, S-Video, RGB, RGBHV, YUV, YC, etc.
Control System Dbstar
Software Xmplayer 3.1
Installation Wall mount, hung

Applications:

Business Organizations supermarket, large-scale shopping malls, , chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations

Banks, negotiable securities, funds, insurance companies, pawnshops;

Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Public Places subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms,
Entertainments Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course

Our Advantage:

With Slim body, light weight, Ultra Thin design, we can help to save space where the space is very highly

required,such as metro station,train station, Airport, shopping mall, retail store and super market, Real

estate, etc.

Front access maintenance available, which will not require to reserve space in the back of the screen.

Foldable LED screen
