Collapsible Stage LED Screens 4x6 Module , Cabinet LED Display Screen Rentals
Collapsible Stage LED Screens 4x6 Module , Cabinet LED Display Screen Rentals
Specifications
Brand Name :
Onumen
Model Number :
OM-F-7P8-N
Certification :
TUV.FCC.CE.ROHS
Place of Origin :
SHENZHEN
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
3000//Square Meter/M
Delivery Time :
25Days
Packaging Details :
Wooden case or flight case as customer's request
Pixel pitch :
7.8mm
Pixel configur :
1R1G1B
Module resolution :
32*32 pixels
Module size :
250*250mm
Module quantity :
16pcs
Brightness :
1500cd/m²
Life time :
10000Hrs
Control system :
BSTAR
Color :
Black
Description

Collapsible Stage LED Screens 4x6 Module , Cabinet LED Display Screen Rentals ​

Flexible Led Display Features :

1. Personalized and complete solution for your case.

2. Factory price and good quality.


3. Convenient and fast installation;Easy maintenance.


3. 2 years warranty and life time maintance.

Technical Specification


Item Technical Specification
Pixel Pixel pitch:7.8mm
Pixel configuration: 1R1G1B
Brightness: Red: 1000mcd Green: 2300mcd Blue: 600mcd
Wave length: Red: 625±2nm Green: 525±2nm Blue: 470±2nm
Module resolution: 32*32 pixels
Module Module size: 250mmx250mm
Cabinet size: 250mm×250mm×23mm
Cabinet Cabinet resolution: 9216 pixels
Cabinet material: 27778 pixels / sqm
Gross weight: 12kg / sqm
Module quantity: 16 pcs= 4(w) x 6(h)
Power consumption : Max.:180W/m² Everage: 90W/m²
Screen Drive method: 1/16 scanning
Brightness: 4000cd/m²
IC driver: MBI 5026
Density: 10000 pixel/m²
Whole display flatness: ≤ 1mm juncture
Best view distance: ≥ 9m
Viewing angle: Horizontal: 120° Vertical: 60°
Humidity(RH): ≤ 90~95%
Working temperature: from -30°C to +60°C
Working voltage: AC220V/110V±10%
Refresh frequency: 2400Hz(Zdec) ≥ 300Hz(Linsn)
Frame rate: ≥ 60Hz
Protection grade: IP54
MTBF: More than 10000hrs
Life time: 100,000 hrs
Control system Control system: BSTAR
Signal interface: AV.USB.DP.SDI
Communication distance: Internet cable: ≤120m / Fiber cable: 1000m
Systems operating platforms : XP,WINDOWS(WIN7,WIN10)

Collapsible Stage LED Screens 4x6 Module , Cabinet LED Display Screen Rentals

FAQ


1. Except this model, are there any other models?


yes, For indoor led screen we have p2.5 p3 p3.91 p4 p4.81 p5 p6 p7.62 p10


For outdoor led screen we have p5 p6 p8 p10


2. Are you factory? and your warranty?


yes we are 8 years factory, 2 years warranty and lifetime maintenance


3. What's the function of your led screen?


It supports videos, flash, WAV/MIDI, PPT, images and so on


4. What's your delivery time?


Wthin 25-28 days after receiving deposit


5. What's your package and shipping way?


Goods are packed with wooden case or flight case; delivered by air or sea
