Indoor Ptich 12mm Foldable LED Screens SMD3528 , Music Concert LED Display192mm × 192mm
Indoor Ptich 12mm Foldable LED Screens SMD3528 , Music Concert LED Display192mm × 192mm
Indoor Ptich 12mm Foldable LED Screens SMD3528 , Music Concert LED Display192mm × 192mm
Indoor Ptich 12mm Foldable LED Screens SMD3528 , Music Concert LED Display192mm × 192mm
Specifications
Brand Name :
ONUMEN
Model Number :
F-P12
Certification :
CE/ROHS/FCC/TUV
Place of Origin :
CHINA
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T 50% deposit,the balance should be paid before shipment
Supply Ability :
1000sqm per month
Delivery Time :
25 working days after received your payment
Packaging Details :
Packed in flightcase
Application :
Indoor
Max Brightness :
1300cm/d
Feature :
slim,lightweight
Type :
SMD3528
Driving Mode :
1/8
Working Power :
DC24V
Module Size :
192mmx192mm
Installation Mode :
Hanging Embedding
Weight :
10kgs/sqm
Average power :
75w/㎡
Pitch :
12mm
Description

Indoor Ptich 12mm Foldable LED Screens SMD3528 , Music Concert LED Display192mm × 192mm

Description:

Slim series is our latest generation fo Onumen flexible LED display

It is the perfect choice for all kinds of advertsing and enteraining purpose ,such as concert,musical

event.club.airport,exhibition,advertisement,...etc.

With highest pixel resolution of 3.9mm,Slim sereis display can be bent in all directions and reshaped as

you need with HD video quality.

Different from the traditional LED display,it is innovative design and future not only represents the

breakthrought of the LED display technology also crests a new era in the history of flexible display

development.

Specifications:

Model No. Slim 12
Pixel Pitch 12mm
Module Size 192x192mm
Module Resolution(pixels) 32*32
Panel Size 768mm×2112mm, be customized as per customer's request. Max can be 768*6144m
Panel Resolution(pixels) 64X176
Pixel Configuration(RGB) 1R1G1B
Pixel Density(pixels/m2) 6944
Brightness(cd/m2) >1300
Best Viewing Distance(m) >12m
Max.Power Consumption(W/m2) 320
Waterproof Level Indoor IP43/Indoor IP54
Power Supply AC110-220V +-15% ,47-63HZ
LED SPEC SMD3528
Viewing Angle 110°(H)/110°(V)
Operating Temperature –20~50°C
Video Frame Rate(Hz) 30-120HZ
Display Refresh Rate(Hz) ≥8000HZ
Grey Level(colors) 16.7million
MTBF ≥50000 hours
Lifespan ≥100000Hours
Working Voltage DC24V
Drive Mode Scan 1/8
Graphics Card DVI Graphics card
Video Signal RF, S-Video, RGB, RGBHV, YUV, YC, etc.
Control System Dbstar
Software Xmplayer 3.1
Installation Wall mount, hung

Applications:

Business Organizations supermarket, large-scale shopping malls, , chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations

Banks, negotiable securities, funds, insurance companies, pawnshops;

Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Public Places subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms,
Entertainments Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course

Indoor Ptich 12mm Foldable LED Screens SMD3528 , Music Concert LED Display192mm × 192mm

Competitive Advantage:

Onumen LED Totem ,a large stand advertising equipment,which makes it perfect and luxury for

advertising.

All stand machine can be installed easily move around easily .All can be cusomized.It depends on your

requirements.

It is a unique design and creative product,hot sell and popular in the market.
