Energy Saving Retail LED Display 4000cd Flexible Video Wall Displays 360 Degree Viewing Angle
Energy Saving Retail LED Display 4000cd Flexible Video Wall Displays 360 Degree Viewing Angle
Specifications
Brand Name :
Onumen
Model Number :
OM-F-7P8-N
Certification :
TUV.FCC.CE.ROHS
Place of Origin :
SHENZHEN
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
3000//Square Meter/M
Delivery Time :
25Days
Packaging Details :
Wooden case or flight case as customer's request
Pixel pitch :
7.8mm
Pixel configur :
1R1G1B
Module resolution :
32*32 pixels
Module size :
250*250mm
Module quantity :
16pcs
Brightness :
1500cd/m²
Life time :
10000Hrs
Control system :
BSTAR
Color :
Black
Description

Energy Saving Retail LED Display 4000cd Flexible Video Wall Displays 360 Degree Viewing Angle​


Flexible Led Display Features :

1. Specifications

a. Globe shape
b. 360 degree viewing angle
c. Standard size:1m to 20m available
d. Aluminum structural design,can be movable


Technical Specification

ItemTechnical Specification
PixelPixel pitch:7.8mm
Pixel configuration: 1R1G1B
Brightness: Red: 1000mcd Green: 2300mcd Blue: 600mcd
Wave length: Red: 625±2nm Green: 525±2nm Blue: 470±2nm
Module resolution: 32*32 pixels
ModuleModule size: 250mmx250mm
Cabinet size: 250mm×250mm×23mm
CabinetCabinet resolution: 9216 pixels
Cabinet material: 27778 pixels / sqm
Gross weight: 12kg / sqm
Module quantity: 16 pcs= 4(w) x 6(h)
Power consumption : Max.:180W/m² Everage: 90W/m²
ScreenDrive method: 1/16 scanning
Brightness: 4000cd/m²
IC driver: MBI 5026
Density: 10000 pixel/m²
Whole display flatness: ≤ 1mm juncture
Best view distance: ≥ 9m
Viewing angle: Horizontal: 120° Vertical: 60°
Humidity(RH): ≤ 90~95%
Working temperature: from -30°C to +60°C
Working voltage: AC220V/110V±10%
Refresh frequency: 2400Hz(Zdec) ≥ 300Hz(Linsn)
Frame rate: ≥ 60Hz
Protection grade: IP54
MTBF: More than 10000hrs
Life time: 100,000 hrs
Control systemControl system: BSTAR
Signal interface: AV.USB.DP.SDI
Communication distance: Internet cable: ≤120m / Fiber cable: 1000m
Systems operating platforms : XP,WINDOWS(WIN7,WIN10)





Energy Saving Retail LED Display 4000cd Flexible Video Wall Displays 360 Degree Viewing Angle



2. What a led display can show exactly?

1. Video play: It can play various signals, such as TV, DVD,VCD. It can also switch to different videos

at any time, and zoom or cut video operation.
2. Word processing: It can display various character with different fronts, types and character

information, it also may roll up the pages, shift, rotate, snow flow, screen rolling, glint and more than

other 10 types display functions.
3. Picture display: It can play various graphics, pictures, such as BMP,JPG,GIF,TIFF,TXT,DOC,PPT

format etc.
4. Cartoon demonstration: It can play two or three cartoons, and revivify the vivid effect of the picture.
5. Random layout: The powerful software can play video images, characters, graphics independently,

tile up the characters information and cartoons etc.

3. Applications of Indoor led display:

1. Television studios, broadcast centers, cinemas.

2. Concert halls, music halls, theaters.

3. Casinos, nightclubs, restaurants, entertainment centers.

4. Exhibition centers, conference rooms,meeting rooms, presentation centers.


4. Product Advantages:

1) Price Advantage: Best competitive price of the market.
2) Performance Advantage: Best brightness, High refresh rate, high consistency, Big viewing angle...

3) Quality advantage: From material to finished product, from design to produce, we control all steps,

that's the guarantee of the quality and reliability.
4) Service advantage: with professional service team for 24 hours service!


5. Why choose CreKing LED ?

1. Pioneer quality with competitive price.

2. Muti-choice for models.(from P2.5mm to P31.25mm)

3. Continuous technical support.

4. Good after-sale service.(Pre-sales, sale,after-sale)

5. Two years quality warranty.
