1000L Beer Brewing Stainless Steel Conical Fermenter
1000L Beer Brewing Stainless Steel Conical Fermenter
1000L Beer Brewing Stainless Steel Conical Fermenter
1000L Beer Brewing Stainless Steel Conical Fermenter
Specifications
Brand Name :
Fude
Model Number :
FD-B-500
Certification :
CE,ISO,UL,3C
Place of Origin :
China
MOQ :
1
Price :
1000-50000
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000
Delivery Time :
7
Packaging Details :
wooden case package
Material :
304stainless steel
Progress :
Fermentig machine
Processing Types: :
Alcohol
Warranty: :
5 years
Core Components: :
Gearbox, Motor, PLC
Cooling way: :
Dimple plate cooling
Thickness of inner jacket: :
3mm
Insulation Materials: :
PU Foma Insulation
Control system: :
PLC
Usage: :
Beer Brewing
Capacity: :
500L
Welding: :
TIG Welding
Polish: :
Ra0.4
Brand :
Fude
Description

Made in china hot sale good quality beer brewing fermenter tank conical fermenter

2020 hot sale high quality 1000L conical fermenter 1000L mash tun beer brewing for sale

1000L Beer Brewing Stainless Steel Conical Fermenter

Application

The whole set equipment is made of austenitic stainless steel.The cooling jacket adopts dimple jacket. The jackets are provided at tank body and conical bottom to effectively increase the cooling speed. Heat exchanging area of jacket of different proportions can be allocated according to customers' technological requirements. Widly used in brewery,bar, hotel,family etc.

Brewhouse System

mash/ lauter tank, kettle/ whirlpool tank, hot water tank; wort pump, hot water pump, heat exchanger,

other accessories: mashing pipes, thermometer, wort oxygenate assembly, titanium stick, survey barrel, sanchorometer, rake, work platform

More details make perfect

1. Polishing:

Polishing is vital for tanks. Tanks should be polished wholly inside and outside.

Therefore it can ensure there is no place for the bacteria to hide in tanks.

Our polishing system consists of auto and semi-auto polishing machine and manual polishing.

Each tank is polished three times and more polish for the key place.

1000L Beer Brewing Stainless Steel Conical Fermenter

1000L Stainless Steel Beer Fermentation Equipment Turnkey Project For Brewery System
1.Malt Milling System
Mill machine
Stainless steel/Carbon steel
Grist case
Stainless steel
Flexible conveyor
Outer PPR or Stainless steel
2.Brewhouse System
Mashtun
-Inner:3mm;outer:2mm
-Motor agitation
-Steam jackets/Electric elements/Fire direct heating
Lauter tun
-Inner:3mm;outer:2mm
-Rack system;
-False bottom filter
Kettle tun
-Inner:3mm;outer:2mm
-Steam jackets/Electric elements/Fire direct heating
Whirlpool tun
-Inner:3mm;outer:2mm
-Side tangent whirlpool inlet
Hot water tank
-Inner:3mm;outer:2mm
-Steam jackets/Electric elements/Fire direct heating
Accessories
-Mash pump;;Heat exchange plate;Hop back system; Brewhouse Pipes;
3.Fermentation System
Fermentation tank
-Pressure:3Bar;
-Inner:3mm;outer:2mm;with insulation;
-Cooling jackets;
Accessories
Yeast Saving Tank;
4.Cooling System
Glycol water tank
-Inner:3mm;outer:2mm
Accessories
Chiller; Glycol water pump; Pipes & Valves;
5.CIP System
Acid tank
Pump; Pipes & Valves
Caustic tank
Trolley
Accessories of the CIP System
6.Control System
-Automatic/Semi-auto
7.Filtering System
Candle type diatomite filter/Membrane filter/Bag filter
Bright beer tank
Double-layer with insulation;
8.Filling System
Glass bottle line
-Capacity:800-1200 BPH
-Washing heads:8;Filling heads:8;Capping heads:3
-Optional:
Capacity:1500-2000 BPH
-Washing heads:16;Filling heads:16;Capping heads:6
Canning line
Capacity:1000-1500 CPH
-Filling heads:12;Capping heads:1
Keg system
Keg filling machine;Keg washing machine;Keg washing and filling unity machine;

1000L Beer Brewing Stainless Steel Conical Fermenter

Pre-sale service

1. Free of making offers, craft and technical guidance.

2. We can provide company’s qualification certification and the drawings.

3. We can also make customized products according to customer’s needs.

After-sale service

1. We provide long-term after-sale service.

2. Owing to the quotation of our equipment is FOB price.Thus, if necessary, we can appoint our technician to debug the machine with air ticket, visa, accommodation and labor cost provided by your party. Or you can send your technician to our company to learn techniques.

3. Meanwhile, you can call or e-mail to consult any relevant questions since we have a special line of after-sale service.
