Products Description:

1, no approval, safety, stability, high efficiency and energy saving

1.1 No application for approval: According to Article 1.3 of "Boiler Safety Technical Regulations" TSG 11-2020, Special Equipment safety Technical Specification of AQSIQ:

The design of normal water level water volume (direct current boiler and other boilers without fixed water and water dividing line, the water volume is calculated according to the total geometric volume in the inlet and outlet of water and water, the same below) is less than 30L, or the rated steam pressure is less than 0.1Mpa steam boiler, does not belong to the scope of boiler supervision. The rated evaporation capacity of this series is 300Kg/

h, 500Kg/h, 1000Kg/h condensing steam generator water volume less than 30L. Using our company's core patented technology to build, less than 30L of water volume, eliminating the complicated use of traditional boilers.

1. 2 Thermal efficiency ≥ 98.7%, exhaust temperature below 60℃, pvc smoke chimney.

2. Environmental protection

Using ultra-low nitrogen burner

2. 1 High-tech crystallization, a new era of combustion.

2.2 NOx≤30mg/m².

2. 3 Aviation metal fiber processing, more energy saving and more environmentally friendly than traditional atmospheric direct combustion.

3, energy saving technology advantage

3.1 Rapid pressure boost, 2 minutes to steam, greatly saving the cost of heating.

3.2 Using static surface combustion, automatically adjust the power of the boiler according to the demand for steam, and replace the size and fire regulation of the traditional boiler with stepless variable speed, saving 10%-30% energy than the traditional boiler.

3. 3 Adopts the unique all-tube return design, which is safer.

3.4 can produce superheated steam, in low pressure environment can produce 180℃ -230 ℃ high temperature steam, so that heating more efficient, less trouble, equipped with energy-saving device, condenser.

4. Safety

4. 1 Use EBM, AMETEK, FASCO brushless PWM fan, a frequency conversion fan that does not produce sparks.

4.2 HONEYWELL Air Fuel ratio Valve Group (Germany) Adaptive air fuel ratio valve group, so that air and gas perform proportional combustion, combustion is more stable.

4. 3 Combination of anti-flue gas backflow protection devices to prevent flue gas backflow to the boiler room.

5, steam constant pressure output technology

The combustion power variable speed function automatically matches the steam pressure to avoid repeated start-stop and output pressure fluctuations.

6, remote management and Internet of Things program control technology:

6. 1 Intelligent control with KUNLUN7 inch LCD touch screen, resolution 800*480, all Chinese graphic menu operation interface;

6. 2 Real-time monitoring data analysis and maintenance reminders, mobile real-time monitoring.

6. 2. 1 Real-time monitoring of boiler and system operation data monitoring, energy efficiency analysis, energy management, so as to provide better solutions for energy-saving transformation;

6. 2. 2 Overall status monitoring of boiler, real-time uploading of fault alarm and video monitoring, real-time sending of alarm information to APP and mobile phone in case of safety, overpressure and water shortage.

6.2. 3 Maintenance reminders

6.3 Maintenance reminder equipment and accessories operation cycle, maintenance analysis, reminder.

4. Storage and analysis of historical data of multi-dimensional storage boiler.

7. Ultra-small footprint

7.1 The floor area is only 1/3 of the traditional boiler.

7.2 Ultra-light weight, 1/5 of the weight of the traditional boiler.

8. Install a personalization device

9.1 Unique burner and body connection parts can be transported and installed separately.

9.2 Modular combination, through the number of "parallel combination" can reach the scale of any single boiler.
