IP54 Chips Metal Detector X Ray Machine Food X Ray Sundries Eliminate Machine
IP54 Chips Metal Detector X Ray Machine Food X Ray Sundries Eliminate Machine
Specifications
Brand Name :
Foodman
Model Number :
FXR-5026K100
Certification :
CE, FDA, ISO9001
Place of Origin :
Guangdong, China
MOQ :
1 Set
Delivery Time :
25 work day
Packaging Details :
Wooden packing
Tunnel size :
500mm(W)*260mm(H)
Dose of x-ray leakage :
<0.1μGy/h
Usage :
Inspect foreign substance
Application :
Food&Beverage,Pharmacy,Health Care Industry,Chemical Industry
Data interface :
LAN Port, USB Port
X-Ray Tube :
350W 100KV / Customization
Power :
Electronic
Color :
Stainless Steel / Customization
After-sales Service Provided: :
Engineers available to service machinery overseas
Name :
X-ray Sundries Eliminate Machine for pharmaceutical factory and else
Description

IP54 Chips Metal Detector X Ray Machine Food X Ray Sundries Eliminate Machine

Latest Easyweigh X-Ray Tube X-ray Machine Food Software Conveyor X-ray Sundries Eliminate Machine

X-ray Sundries Eliminate Machine for Wrapping Goods

IP54 Chips Metal Detector X Ray Machine Food X Ray Sundries Eliminate Machine

FXR50 series Xray Inspection System is suitable inspect small packages like biscuits, chips, baby foods, medicine

The machine suitable packaged and unpackaged goods like food,pharmaceutical and chemical products.

IP54 Chips Metal Detector X Ray Machine Food X Ray Sundries Eliminate Machine

• Strong adaptability to the environment:Germanair-conditioner ensure the machine can work in low and high temperature in foodindustry.Sealingsystem to avoid water and dust.High-performancedehumidifier can work in 90% humid environment.

• Intuitive operation interface:17 inches full colour touch screen,easy to use.Auto-analysis on inspected product,simple to set up inspecting parameter.Auto-save inspection photos, easy totrack and control.

• Easy cleaning and maintenance: Detachable structure makes cleaning easy.Waterproof washdown construction, IP66 for detectingtunnel, IP54 for rest of the body.

• High configuration and stability:Main components are first class brand toensure the stability and working lifetime.

• Safe and reliable : X-Ray leakage is less than 1μ Sv/hour,complying with FDA and CE standard. Radiation less than 1 Gy, very safe for food.Designed complete shielded structure, prevent leakage accident.

IP54 Chips Metal Detector X Ray Machine Food X Ray Sundries Eliminate Machine

Model FXR-2417K100 FXR-4017K100 FXR-5026K100 FXR6035K100
X-Ray Tube 150W 100KV 210W 100KV 350W 100KV
Conveyor Size Width 240mm 400mm 500mm 600mm
Height 170mm 170mm 260mm 350mm
Sensitivity Stainless steel ball φ0.3mm,Stainless steel wire φ0.2*2mm
Conveyor Speed 10～70m/min
Display Screen 17inches colour touch screen
Interface LAN Port,USB Port
Environment

Temperature:-10℃～40℃(with on-board air conditioner),

Humidity:30%～90%(equipped with dehumidifier)
X-Ray Emission ＜1μSv/hour
X-Ray Protection Light weight lead-free soft curtains at tunnel
Reaction to defective Sound and indicator, stopping machine, rejector
Power AC220V±10%50Hz(60Hz)1.5kVA Max
Waterproof IP66
Body Material 304 Stainless Steel
