1500mm Digital Metal Detector Chain Conveyor For Meat Poultry Products
1500mm Digital Metal Detector Chain Conveyor For Meat Poultry Products
Specifications
Brand Name :
Easyweigh
Model Number :
FMD-4009 /4012/4015/4017/4020
Certification :
CE, FDA, ISO9001
Place of Origin :
China
MOQ :
1 Set
Delivery Time :
25 work day
Packaging Details :
wooden package
Size of Effective Width(mm) :
400
Size of Effective Height :
90/120/150/170/200
Width of PU Belt(mm) :
380
Length of conveyor (Without rejector) :
1200
Belt height, above ground (mm) :
800±50
Belt speed(m/min.) :
32
Sensitivity (Air test of center) (mm) :
FE:1.0 NFE:1.5 SUS304:2.0
Maximum Weights to drive (KG) :
25
Sorting/Rejecting device :
Down belt,Flipper, Pusher
Description

1500mm Digital Metal Detector Chain Conveyor For Meat Poultry Products

Digital Metal Detector (chain conveyor) for Meat and Poultry Products

Application:

The equipment is widely used in Aquatic products,fresh meat,frozen meat ,preserved meat,and poultry products,

and so on to ensure contaminated product is detected.

Characteristics:

1 Adapt phase discriminating technology that can effectively refrain product effect;
2 Adapt advanced DSP technology and leading intelligent algorithm which can

improve detection sensitivity and promote stability of the machine;
3 Be able to detect various metals like iron, stainless teel,copper and aluminum, etc;
4 Chinese & English operating menu;
5 Self-learning function contributes to automaticallychoose suitable working parameters

according to different products;
6 Memory function for registering various products(Max: Over 20 Items);
7 Simple conveyor structure makes it convenient to disassembleand assemble;
8 Special design of conveyor belt for aquatic products and frozen foods;

9 Made of stainless steel, fairly good waterproof ability;

10Excellent quality with attractive price.

Technical Parameters:

Model 3009 3012 3015 4009 4012 4015 4017 4020 5509 5520 5525
Height (mm) 90 120 150 90 120 150 170 200 90 200 250
Width (mm) 300mm 400mm 500mm
Body Length(mm) 1500mm
Conveyor 32m/min
Max Capacity 10KG 50KG
Sensitivity FE 0.7 0.8 1.0 0.8 1.0 1.0 1.2 1.2 0.8 1.2 2.0
NFE 1.0 1.2 1.5 1.0 1.2 1.5 1.8 1.8 1.2 2.0 2.5
SUS304 1.5 1.5 2.0 1.5 1.5 2.0 2.5 2.5 1.5 2.5 3.0
Power AC220V±10% 50Hz (60Hz)
Operation Mode Button
Alarm Alarm to stop transfer or reject setting
Waterproof IP54/IP66
Working Environment Temperature:-10℃～40℃,Humidity:30%～95%
Body Construction Stainless Steel 304
