Large Diameter Reducer Alloy Steel Pipe Fittings Sch 40 ASTM A234 WP22 ASME 16 9
Large Diameter Reducer Alloy Steel Pipe Fittings Sch 40 ASTM A234 WP22 ASME 16 9
Large Diameter Reducer Alloy Steel Pipe Fittings Sch 40 ASTM A234 WP22 ASME 16 9
Large Diameter Reducer Alloy Steel Pipe Fittings Sch 40 ASTM A234 WP22 ASME 16 9
Large Diameter Reducer Alloy Steel Pipe Fittings Sch 40 ASTM A234 WP22 ASME 16 9
Large Diameter Reducer Alloy Steel Pipe Fittings Sch 40 ASTM A234 WP22 ASME 16 9
Large Diameter Reducer Alloy Steel Pipe Fittings Sch 40 ASTM A234 WP22 ASME 16 9
Large Diameter Reducer Alloy Steel Pipe Fittings Sch 40 ASTM A234 WP22 ASME 16 9
Specifications
Brand Name :
ZZ
Model Number :
ASTM A234 WP22
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, D/P, D/A, L/C
Supply Ability :
50000 PCS Per Month
Delivery Time :
5-20 Days
Packaging Details :
1/2" to 16" in Wooden Cases. Above 16" in wooden Pallets
Material :
Alloy Steel
Standard :
ANSI, ASME B36.19, B16.9
Shape :
Round
Size :
1/2" - 60"
Thickness :
sch10s, 20, 40, STD, XS, 80, 100, 120, 140, 160, XXS
Products :
90 Degre Elbow, 45 Degree Elbow, Concentric Reducer, Eccentric Reducer, Equal Tee, Reducer Tee, Pipe Cap, End Cap
Packing :
Plastic Foam, Wooden Cases, Pallets
Application :
Industry, Natural Gas , Petroleum, Gas And Oil Pipes, Chemical
Description

Large Diameter Reducer Sch 40 ASTM A234 WP22 Alloy Steel Pipe Fittings ASME16.9

Large Diameter Reducer

Top Exporter&Distributor of Large Diameter Reducer Sch 40 ASTM A234 WP22 Alloy Steel Pipe Fittings ASME16.9 at the most attractice price for Malaysia.

Large diameter pipe reducers have concentric and eccentric types. Both Concentric and Eccentric Reducer are butt weld fittings. They are same as forged fittings that Concentric Swage and Eccentric Swage.

Butt Weld Reducer Dimensions

Size 1/2" - 60"
Wall Thickness Sch10S, 20S, 40S, STD, XS, 80S, 100, 120, 140, 160, XXS
Standard ASME B36.19
Types Seamless Reducer, Welded Reducer, Concentric Reducer, Eccentric Reducer
Stainless Steel ASTM A403 WP304/304L/304H, WP316/316L, WP310, WP317, WP321
Duplex Steel ASTM A815 UNS S 31803, S 32205, S 32550, S 32750, S 32760
Carbon Steel ASTM A234 WPB, A860 WPHY42, 52, 60, 65, 70
Low Temp Carbon Steel ASTM A420 WPL3, WPL6, WPL9
Alloy Steel ASTM A234 WP1, WP5, WP9, WP11, WP12, WP22, WP91

Steel Pipe Reducer Weight

The weights of concentric and eccentric reducer with same dimensions are the same. The diameters of pipe reducers below 24 inches are more common.

Large Diameter Reducer Alloy Steel Pipe Fittings Sch 40 ASTM A234 WP22 ASME 16 9

How to Calculate Pipe Reducer Weight

  • 0.02466 × S ×[ (D+d)/2-S] × H / 1000
  • S: Wall thickness
  • D: Outside diameter of the larger end
  • d: Outside diameter of the small end
  • H: End to end dimension

Concentric and Eccentric Reducers

Package

  • Clear marking on the surface.
  • Wrapped pipe fittings with plastic foam.
  • Packed large diameter pipe reducers on wooden pallets.

Inspection

  • Surface. Visual and touch, avoid dents, die marks, undercuts.
  • Marking. Covers size, material grade, pressure, standard heat No.
  • Size. Measure and record, ensure they are in tolerance.

Large Diameter Reducer Alloy Steel Pipe Fittings Sch 40 ASTM A234 WP22 ASME 16 9

Application

  • Oil and Gas
  • Chemical
  • Natural Gas
  • Petroleum
  • Food Industry

ASTM A234 WP22 Chemical Composition

C Mn P S Si Cr Mo
0.05-0.15 0.3-0.6 0.04 0.04 0.5 2-2.5 0.87-1.13

ASTM A234 WP22 Mechanical Properties

Tensile Strength Yield Strength Elongation
415-585 (Mpa) 205 (Mpa) 20(%)
