Specifications
Brand Name :
ZZ
Model Number :
ASTM A182 F316
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram, D/P, D/A, L/C
Supply Ability :
60000 PCS Per Month
Delivery Time :
10-15 Days
Packaging Details :
Cartons and Wooden Cases
Material :
ASTM A182 F316
Connection :
SW
Type :
90 Degree Socket Weld Elbow, 45 Degree Socket Weld Elbow
Size :
1/8", 1/4", 3/8", 1/2", 1/4", 1", 1 1/4", 1 1/2", 2", 2 1/2", 3", 4"
Pressure :
3000 LB, 6000 LB, 9000 LB
Standard :
ASME B16.11, BS3799
Surface :
Anti rust Oil, Galvanized
Packing :
Carton, Wooden Case
Description

90 Degree Socket Weld Elbow 3 " 6000 LB SS 316 ASME B16.11 Steel Pipe Elbow

Stainless Steel Elbows

ISO certified company Zizi manufactures 90 Degree Socket Weld Elbow 3 " 6000 LB with best quality SS 316 in accordance with ASME B16.11. We supply steel pipe elbows with socket weld end, threaded end and buttweld end.

Butt weld is the most common used and stable connection type among steel elbows, but it is more common in large diameter pipelines. Among small diameter pipe systems, socket weld elbow performe very good.

Socket Weld Elbow Dimensions

Size 1/8" to 4" / DN6 to DN100
Pressure Rating Class 3000, 6000, 9000
Standard ASME B16.11 and BS3799
Surface

Anti-rust Oil or Galvanized
Product 90 Degree Socket Weld Elbow,45 Degree Elbow, Equal Tee, Reducing Tee, Socket Weld Coupling, Cap and Union
Stainless Steel ASTM A182 F304/304L, F304H, F316/316L, F310, F317, F321
Caron Steel ASTM A105, A350 LF2, LF3, A694 F52, F60, F65, F70
Alloy Steel ASTM A182 F1, F5, F9, F11, F12, F22, F91
Duplex Steel ASTM A182 F51, F53, F55, S 31803, S 32205, S 32550, S 32750, S 32760

90 Degree Socket Weld Steel Pipe Elbow 3

90 Degree Socket Weld Elbow Weight Chart

Here is the weights of 90 degree socket weld elbow, the dimensions we give is in accordance with ASME B16.11.

90 Degree Socket Weld Steel Pipe Elbow 3

Package of 3" 90 Degree ELbow

  • Marking. Mark Grade, Lot No, Size, Standard and Pressure at the surface.
  • Wrapped each 90 degree elbow with plastic foam
  • Packed all 3" elbows into cartons and wooden cases.

Inspection of SS 316 Fittings

  • Visual the surface. Such as dents, die marks, porosity, undercuts.
  • Check the marking. Such as size, material grade, pressure, heat no.
  • Measure the size. Such as diameter, thickness, height of end to end.
  • Test the properties of stainless steel 316 fittings

ASTM A182 F316 Chemical Composition

C Mn P S Si Ni Cr Mo
0.08 2 0.035 0.03 1 10-14 16-18 2-3

ASTM A182 F316 Mechanical Properties

Tensile Strength Yield Strength Elongation
515 (Mpa) 205 (Mpa) 30 (%)

Advantage of Forged Steel Fittings

  • Reasonable Price
  • Good Quality
  • Fast Delivery
  • Good Service
