45 Degree Male Threaded Elbow , ASTM A182 F53 Steel Gas Pipe Fittings ASME B16 11
45 Degree Male Threaded Elbow , ASTM A182 F53 Steel Gas Pipe Fittings ASME B16 11
45 Degree Male Threaded Elbow , ASTM A182 F53 Steel Gas Pipe Fittings ASME B16 11
45 Degree Male Threaded Elbow , ASTM A182 F53 Steel Gas Pipe Fittings ASME B16 11
45 Degree Male Threaded Elbow , ASTM A182 F53 Steel Gas Pipe Fittings ASME B16 11
45 Degree Male Threaded Elbow , ASTM A182 F53 Steel Gas Pipe Fittings ASME B16 11
45 Degree Male Threaded Elbow , ASTM A182 F53 Steel Gas Pipe Fittings ASME B16 11
45 Degree Male Threaded Elbow , ASTM A182 F53 Steel Gas Pipe Fittings ASME B16 11
Specifications
Brand Name :
ZZ
Model Number :
ASTM A182 F53
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram, D/P, D/A, L/C
Supply Ability :
60000 PCS Per Month
Delivery Time :
5-15 Days
Packaging Details :
Cartons and Wooden Cases
Material :
ASTM A182 F53
Connection :
Female and Male Thread
Products :
90 Degree Elbow,45 Degree Elbow, Equal Tee, Reducing Tee, Threaded Coupling, Cap and Union
Size :
1/8", 1/4", 3/8", 1/2", 1/4", 1", 1 1/4", 1 1/2", 2", 2 1/2", 3", 4"
Pressure :
2000 LB, 3000 LB, 6000 LB
Standard :
ASME B16.11, BS3799
Thread :
NPT, BSPP, BSPT
Surface :
Anti rust Oil, Galvanized
Packing :
Plastic Foam, Carton and Wooden Case. 20FT Container
Application :
Industry, Petroleum, Gas And Oil Pipes, Chemical
Description

45 Degree Threaded Elbow 1 1 / 2" BSPP Class 3000 ASTM A182 F53 ASME B16.11

ASME Threaded Elbow

45 degree threaded elbow 1 1/2" BSPP Class 3000 ASTM A182 F53 ASME B16.11 is supplied in best quality material of duplex stainless steel, meet your demands for strong joint in small diameter pipe systems.

Threaded Elbow are mainly used for small pipe diameters (Small Bore Piping), generally for piping whose nominal diameter is NPS 4 or smaller. Compare to socket weld fittings, it is no need to welding and quickly installed.

45 Degree Threaded Elbow Dimensions

Size NPS 1/8" to 4" / DN 6 to 100
Pressure Rating 2000#, 3000#, 6000#
Standard ASME B16.11, BS3799, GB/T14626
Surface

Anti-rust Oil or Galvanized

45 Degree Male Threaded Elbow , ASTM A182 F53 Steel Gas Pipe Fittings ASME B16 11

Alloy Steel 45 Degree Elbow

ASTM A182 F1, F5, F9, F11, F12, F22, F91

Stainless Steel Threaded Elbow

ASTM A182 F304/304L/304H, F316/316L, F310, F317, F321, F347

Carbon Steel BSP 90 Degree Elbow

ASTM A105, A350 LF2, LF3, A694 F52, F60, F65, F70

Duplex Steel Class 3000 Forged Elbow

ASTM A182 F51, F53, F55, F56, S 31803, 32205, 32550, 32750, 32760

ASTM A182 F53 Chemical Composition

C Mn P S Si Ni Cr Mo
0.03 1.2 0.035 0.8 1 6-8 24-26 3-5

ASTM A182 F53 Mechanical Properties

Tensile Strength Yield Strength Elongation
800 (Mpa) 550 (Mpa) 15 (%)

Threaded 45 Degree Elbow Weight

45 Degree Male Threaded Elbow , ASTM A182 F53 Steel Gas Pipe Fittings ASME B16 11

Package of 45 Degree Elbow

  • Marked with Grade, Lot No, Size, Standard and Pressure.
  • Wrapped forged steel elbow with plastic foam
  • Packed Threaded fittings into cartons and wooden cases.

Inspection of Threaded Elbow Class 300

  • Visual the surface. Such as smooth, dents, die marks, porosity, undercuts.
  • Check the marking. Such as size, grade, pressure, standard, heat No.
  • Measure the size. Such as diameter, thickness, height of end to end.
  • Check the thread with go/no go gauge.
  • Test chemical composition of duplex stainless steel elbow.

Why Choose Us?

  • Attractive price
  • ISO certified quality
  • Delivery in short time
  • Good package
  • Abundant stock
