Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16 11
Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16 11
Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16 11
Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16 11
Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16 11
Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16 11
Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16 11
Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16 11
Specifications
Brand Name :
ZZ
Model Number :
ASTM A182 F304
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram, D/P, D/A, L/C
Supply Ability :
60000 PCS Per Month
Delivery Time :
7-10 Days
Packaging Details :
Cartons and Wooden Cases
Standard :
DIN, ANSI, ASME B16.11, BS, JIS, ASMT, GB
Size :
1/8", 1/4", 3/8", 1/2", 1/4", 1", 1 1/4", 1 1/2", 2", 2 1/2", 3", 4"
Pressure :
3000 LB, 6000 LB, 9000 LB
Type :
Elbow, Tee, Union, Coupling, Cap
Material :
Stainless Steel, Carbon Steel and Alloy Steel
Packing :
Plastic Foam, Carton & Wooden Case, 20FT Container
Description

Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16.11

Forged Steel Pipe Fittings Cross

Leading manufacturer Zizi offers high quality Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16.11 in various dimensions and best price.

What is Pipe Cross?

Pipe cross is smailiar with pipe tee, which is used to connect pipes and provide branches. It has four outlets. It is available in socket weld end, threadede end and butt weld end. And butt weld cross has larger dimension ranges than the other two types.

Socket Weld Cross Dimensions

Size NPS 1/8" to 4" / DN6 to DN100
Pressure Rating 3000LB, 6000LB, 9000LB
Standard ASME B16.11, BS3799, GB/T14626
Surface

Anti-rust Oil or Galvanized
Alloy Steel ASTM A182 F1, F5, F9, F11, F12, F22, F91
Carbon Steel ASTM A105, A350 LF2, LF3, A694 F52, F60, F65, F70
Stainless Steel ASTM A182 F304/304L/304H, F316/316L, F310, F317, F321, F347
Duplex Stainless Steel ASTM A182 F51, F53, F55,F56, S31803, S32205, S32550, S32750, S32760

Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16 11

ASTM A182 F304 Chemical Composition

C Mn P S Si Cr Ni
0.08 2 0.045 0.03 1 18-20 8-11

ASTM A182 F304 Mechanical Properties

Tensile Strength Yield Strength Elongation
515 (Mpa) 205 (Mpa) 30 (%)

Socket Weld Cross Weight Chart

The weight chart are available in 1/8" to 4" in pressure of 3000LB, 6000LB and 9000LB.

Stainless Steel Pipe Cross Socket Weld Pipe Fittings ASTM A182 F304 ASME B16 11

Stainless Steel Pipe Fittings

Marking

We do marking covers name, size, pressure, thread, material and heat No. on pipe cross body.

Surface

Use anti-rust oil to protect pipe cross during the shipping.

Wrapped these cross tee with plastic film.

Package

Line up all socket weld cross into cartons.

Pack all cartons in wooden cases and bundle it with belts.

Shipping mark on the outside of wooden case for easy indentification.

Advantage

  • Low Cost
  • High Quality
  • Fast Delivery
  • One Step Service
