90 Degree Forged Steel Elbow , SW 1 6000 # DIN Galvanized Pipe Fittings
90 Degree Forged Steel Elbow , SW 1 6000 # DIN Galvanized Pipe Fittings
Specifications
Brand Name :
ZZ
Model Number :
ASTM A105
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram, D/P, D/A, L/C
Supply Ability :
50000 PCS Per Month
Delivery Time :
8-15 Days
Packaging Details :
Cartons and Wooden Cases
Standard :
DIN, ANSI, ASME B16.11, BS, JIS, ASMT, GB
Size :
1/8", 1/4", 3/8", 1/2", 1/4", 1", 1 1/4", 1 1/2", 2", 2 1/2", 3", 4"
Pressure :
3000 LB, 6000 LB, 9000 LB
Surface :
Anti rust Oil, Galvanized
Packing :
Plastic Foam, Carton and Wooden Case. 20FT Container
Application :
Industry, Petroleum, Gas And Oil Pipes, Chemical
Description

Forged Steel Elbow 90 Degree SW 1" 6000# Pipe Fittings ASTM A105 ASME B16.11

Forged Steel Fittings

One of top quality manufacturer and supplier of forged steel pipe fittings and flanges, always supplies 90 degree elbow SW 1" 6000# ASTM A105 ASME B16.11 for South Africa in attractive price.

What is Socket Weld Elbow?

Socket weld method is a pipe insert into a recessed area of a elbow. In contrast to buttweld elbows, socket weld elbows are mainly used for small pipe diameters (Small Bore Piping); generally for piping whose nominal diameter is NPS 4 or smaller.

Socket Weld Fittings Dimensions

Size NPS 1/8" to 4" / DN6 to DN100
Pressure Rating 3000LB, 6000LB, 9000LB
Standard ASME B16.11, BS3799, JIS B2316, SH3410, HG/T21634
Surface

Anti-rust Oil or Galvanized
Product Socket Weld Elbow, Tee, Cross, Cap, Coupling, Lateral
Carbon Steel ASTM A182 F1, F5, F9, F11, F12, F22, F91
Caron Steel ASTM A105, A350 LF2, LF3, A694 F52, F60, F65, F70
Stainless Steel ASTM A182 F304/304L/304H, F316/316L, F310, F317, F321, F347
Duplex Steel ASTM A182 F51, F53, F55,F56, S31803, S32205, S32550, S32750, S32760

Socket Weld Elbow Weight Chart

The diameter range of socket weld elbow is from 1/8 inch to 4 inch and the pressure rating covers 3000LB, 6000LB and 9000LB. There are two types that 45 degree elbow and 90 degree elbow. Now providing 90 degree socket weld elbow weight chart which covers whole diameter and pressure ranges.

90 Degree Forged Steel Elbow , SW 1

1" Socket Weld Elbow

Marking

We do marking as " SW ELBOW 1" 6000# ASTMA105 178" on elbows body, it covers type, name, size, pressure, material and heat No.

Surface

Make the forged steel elbow body surfaced with the anti-rust oil.

Wrapped these elbows with plastic film.

Package

Pack 1" socket weld fittings into cartons.

Put all cartons in wooden cases and bundle it with belts.

Shipping mark on the outside of wooden case for easy indentification.

Application

  • Marine industry
  • Chemical industry
  • Oil & gas industry
  • Pipeline engineering
  • Petrochemical industry

ASTM A105 Chemical Composition

C Mn P S Si Ni Cr Mo
0.35 0.6-1.05 0.035 0.04 0.1-0.35 0.4 0.3 0.12

ASTM A105 Mechanical Properties

Tensile Strength Yield Strength Elongation HB
485 (Mpa) 250 (Mpa) 22 (%) 187
