Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2 3000LB Pressure
Specifications
Brand Name :
ZZ
Model Number :
316 Stainless Steel
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram, D/P, D/A, L/C
Supply Ability :
60000 PCS Per Month
Delivery Time :
7-10 Days
Packaging Details :
Cartons and Wooden Cases
Standard :
DIN, ANSI, BS, JIS, ASME, GB
Size :
1/8"-4",DN6~DN100
Material :
Carbon Steel,Stainless Steel, Alloy Steel
Pressure :
3000PSI, 6000LBS, High Pressure
Surface treatment :
Polished and Anodized,rust-proof black oil
Usage :
oil gas pipe fittings connector,Oil Gas Water Industrial,Joining Pipe Lines
Description

Socket Weld Lateral Tee 45 Degree 1 / 2 " 3000LB Forged Pipe Fitting SS316

Forged Steel Lateral

Quality supplier, exporter, manufacturer of forged steel lateral pipe fittings, offer socket weld 45 degree lateral Tee 1/2" 3000LB SS316 ASME B16.11 for Lagos Nigeria.

What is Lateral Pipe Fitting

Lateral pipe fittings have two types that lateral tee and latrolet (also called Lateral Outlet). The shape of lateral tee is like a pipe tee which have three types, ASME B16.9 butt welding lateral tees, ASME B16.11 socket weld lateral tees and threaded lateral tees.

Socket Weld Lateral Dimensions

Size NPS 1/8", 1/4“, 3/8", 1/2", 1", 1 1/4", 1 1/2", 2"
Pressure Rating 3000LB, 6000LB
Standard ASME B16.11, BS3799, JIS B2316, SH3410, HG/T21634
Alloy Steel ASTM A182 F1, F5, F9, F11, F12, F22, F91
Carbon Steel ASTM A105, A350 LF2, LF3, A694 F52, F60, F65, F70
Stainless Steel ASTM A182 F304/304L/304H, F316/316L, F310, F317, F321, F347
Duplex Stainless Steel ASTM A182 F51, F53, F55,F56, S31803, S32205, S32550, S32750, S32760

Socket Weld Lateral Tee Forged Pipe Fittings 45 Degree 1 / 2

Stainless Steel 316 Chemical Composition

C Mn P S Si Ni Cr Mo
0.08 2 0.035 0.03 1 10-14 16-18 2-3

Stainless Steel 316 Mechanical Properties

Tensile Strength Yield Strength Elongation
515 (Mpa) 205 (Mpa) 30 (%)

1/2 Socket Weld Lateral

Marking

The marking will be " SW Lateral 1/2" 3000LB SS316 Z158", it covers type, product, size, pressure, material and heat No.

Surface

Brushing the forged steel lateral with the anti-rust oil againest rust.

Coating small socket weld fittings with plastic film.

Package

Lining up 1/2" stainless steel lateral tees into cartons.

Put all cartons in wooden cases and bundle it with belts.

Stick the waterproof paper of shipping mark on the outside of packages

Why Choose Us?

  • Offer in time
  • One stop service
  • Reasonable price
  • Short delivery time
  • ISO quality certified
