DN400 X DN350 Steel Pipe Reducer Sch 10S Duplex Steel S31803 Galvanized Surface
DN400 X DN350 Steel Pipe Reducer Sch 10S Duplex Steel S31803 Galvanized Surface
Specifications
Brand Name :
ZZ
Model Number :
ASTM A815 UNS S31803
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, D/P, D/A, L/C
Supply Ability :
60000 PCS Per Month
Delivery Time :
10-20 Days
Packaging Details :
1/2" to 16" in Wooden Cases. Above 16" in wooden Pallets
Standard :
ASME B36.19, B16.9
Size :
1/2" - 60"
Thickness :
sch10s, 20, 40, STD, XS, 80, 100, 120, 140, 160, XXS
Products :
90 Degre Elbow, 45 Degree Elbow, Concentric Reducer, Eccentric Reducer, Equal Tee, Reducer Tee, Pipe Cap, End Cap
Surface :
Galvanized, Black Primer, PE Coating
Type :
Concentric and Eccentric Reducer, Seamless and Welded
Packing :
Plastic Foam, Wooden Cases, Pallets.
Application :
Industry, Natural Gas , Petroleum, Gas And Oil Pipes, Chemical
Description

Concentric Reducer DN400 X DN350 Sch 10S Duplex Steel S31803 Pipe Reducer

Duplex Stainless Steel Pipe Fittings

Best quality Duplex Steel S31803 Pipe Reducer DN400 X DN350 Sch 10S Concentric has a large inventory, they have been exported to Australia and multiple countries in Southeast Asia, Africa and South America.

Duplex stainless steel almost has the best performance among all kinds of manterials. It has excellent strength, toughness and ductility, and its corrosion resistance and stress corrosion cracking resistance are also very good. So duplex steel reducers are very durable and suitable for many industries.

Steel Pipe Reducer Dimensions

Size 1/2" - 60"
Wall Thickness Sch10S, 20S, 40S, STD, XS, 80S, 100, 120, 140, 160, XXS
Standard ANSI / ASME B36.19, B16.9
Form Seamless Reducer, Welded Reducer
Stainless Steel ASTM A403 WP304/304L,WP304H,WP316/316L,WP310,WP317,WP321
Duplex Steel ASTM A815 UNS S 31803, S 32205, S 32550, S 32750, S 32760
Carbon Steel ASTM A234 WPB, A860 WPHY42, 52, 60, 65, 70
Low Temp Carbon Steel ASTM A420 WPL3, WPL6, WPL9
Alloy Steel ASTM A234 WP1, WP5, WP9, WP11, WP12, WP22, WP91

DN400 X DN350 Steel Pipe Reducer Sch 10S Duplex Steel S31803 Galvanized Surface

Concentric Reducer Weigh

This weight chart covers reducer weights from diameter 1/2" to 24", schedule 20 to schedule 160, other dimensions is omitted because of the limited space.

DN400 X DN350 Steel Pipe Reducer Sch 10S Duplex Steel S31803 Galvanized Surface

How to Calculate Pipe Reducer Weight

  • 0.02466 × S ×[ (D+d)/2-S] × H / 1000
  • S: Wall thickness
  • D: Outside diameter of the larger end
  • d: Outside diameter of the small end
  • H: End to end dimension

Package of Sch 10S Stainless Steel Fittings

  • Marking at reducer surface: Grade, Lot No, Size, Standard and Pressure.
  • Wrapped each steel pipe reducer with plastic foam.
  • Packed Sch10s Concentric Reducer into wooden pallets.
  • Tagged labers on the outside of the package for easy indentification.

Inspection of Concentric Buttweld Reducer

  • Visual check and touch the surface. make sure there is no dents, die marks, porosity, undercuts.
  • Check the marking. The size, material grade, pressure, heat no. should be clear.
  • Measure and record the diameter, thickness, end to end of reducers, ensure they are in tolerance.
  • Test the chenical compositon.

DN400 X DN350 Steel Pipe Reducer Sch 10S Duplex Steel S31803 Galvanized Surface

ASTM A815 UNS S31803 Chemical Composition

C Mn P S Si Cr Mo
0.03 2 0.03 0.02 1 21-23 2.5-3.5

ASTM A815 UNS S31803 Mechanical Properties

Tensile Strength Yield Strength Elongation
620 (Mpa) 450 (Mpa) 25 (%)

Advantage of Steel Pipe Reuducer

  • High Performance
  • Anti-corrosive
  • Low cost
  • Good Service
