Rigid Arm Forklift Clamp Attachment 665mm Height Forklift Parts Supplier
Rigid Arm Forklift Clamp Attachment 665mm Height Forklift Parts Supplier
Specifications
Brand Name :
Bonafe
Place of Origin :
China
MOQ :
1 Units
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000 Unit/Units per Year
Delivery Time :
5-8 work days
Product Category: :
Forklift Attachments
Place of Origin: :
China
Material: :
Steel
Applicable Industries: :
Manufacturing Plant, Retail, Advertising Company, Logistics
Overall Height: :
665mm
Weight: :
465kg
Opening Range： :
410-1570mm
Vertical Center of Gravity: :
260mm
Horizontal Center of Gravity: :
355mm
Effective Thickness: :
175mm
Description

Multi-purpose fixture for forklift accessories 1.5T

Parameter

Rigid Arm Forklift Clamp Attachment 665mm Height Forklift Parts Supplier

Capacity@
Load Center
(Kg@mm)		 Model No. Mounting Class Opening Range
(mm)		 Arm Height
A(mm)		 Arm
Length
B (mm)		 Frame
Width
D (mm)		 Arm
Thickness
C (mm)		 Overall
Height
H (mm)		 Vertical
Center of
Gravity
CGV(mm)		 Weight
(kg)		 Effective
Thickness
ET(mm)		 Horizontal
Center of
Gravity
CGH(mm)
1400@500 MCS15D-001A II 420-1570 455 955 865 55 665 260 465 175 355
1400@500 MCS15D-002A II 520-1720 415 1220 865 70 665 220 485 195 415

MCS15D-001A Arm Height:455, Arm Length:955, Frame Width:865, Arm Thickness:55

MCS15D-002A Arm Height:415, Arm Length:1220, Frame Width:865, Arm Thickness:70

Functions & Applications

It efficiently and economically manages almost all types of cardboard, wooden boxes, metal boxes and packaged products, including tobacco, newspaper paper, chemical fibres, laboratories and ports. Efficient and economical management without work platform

Options

* User defined opening range

* Custom pad size

* Various installation categories are available

* Load backrest

Remark:

1. Obtain the actual capacity of the forklift and attachments from the forklift manufacturer.

2. Two sets additional oil circuit required on forklift.

3. Opening range is the space between two arms tip.

4. Arm thickness “C” is the actual requested operation space.

5. Rotating multi-purpose clamps can be choose able.

Other size available on request.


Options:

* Raise and thicken the arms.

* Left and right gripper arms are independent joints.

* 180 degree rotation stop mechanism.

Rigid Arm Forklift Clamp Attachment 665mm Height Forklift Parts Supplier

Applicable Industries

Production plant, retail sale, advertising companies, logistics

Can be customized according to size

Customized solutions:

1. Carton Clamp

2. Block Clamp

3. Bale Clamp

4. Roll Clamp

......

all kinds of attachment
