1900kg Plastic Hydraulic Drum Grabber Forklift Attachment
1900kg Plastic Hydraulic Drum Grabber Forklift Attachment
1900kg Plastic Hydraulic Drum Grabber Forklift Attachment
1900kg Plastic Hydraulic Drum Grabber Forklift Attachment
Specifications
Brand Name :
Bonafe
Place of Origin :
China
MOQ :
1 Units
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000 Unit/Units per Year
Delivery Time :
5-8 work days
Product Category: :
Forklift Drum Clamp
Material: :
Steel
Applicable Industries: :
Widely used in the petroleum and chemical industry
Weight: :
270kg
CGV： :
210mm
Opening Range: :
485-1600mm
Horizontal Center of Gravity: :
107mm
Effective Thickness: :
140mm
Description

1400KG forklift double cylinder side moving fixture

Functions & Applications

The utility model is widely used in petroleum, chemical industry and other applications that need to process standard barrels.

Features

* Durable aluminum guide block structure.

* High strength sliding rod improves the service life of sliding bearing.

* Reasonable roller movement position to prolong the service life of the roller. Replace the rubber pad arm.

* Quick installation, convenient maintenance and excellent display effect.

Options

* Install different available categories

* Initial appropriation

Parameter

1900kg Plastic Hydraulic Drum Grabber Forklift Attachment

Capacity@
Load Center
(Kg@mm)		 Model No. Opening
Range
O
(mm)		 Frame
Width
C
(mm)		 Overall
Height
D
(mm)		 Hook
Spread
E
(mm)		 Vertical
Center of
Gravity
CGV
(mm)		 Weight
(kg)		 Effective
Thickness
ET(mm)		 Horizontal
Center of
Gravity
CGH(mm)
2-Drum Sideshifting
1400@500 DTS15D-001A 395-1545 940 645 890 210 285 145 100
1400@500 DTS15D-002A 485-1600 865 620 760 210 270 140 107
1900@500 DTS15D-002A 520-1750 940 620 760 220 295 145 104

Other size available on request.

Installation & Option

Hydraulic Flow & Pressure

Model Min.
Hydraulic
Flow(L/min)		 Rec.
Hydraulic
Flow(L/min)		 Max.
Hydraulic
Flow(L/min)		 Min.
Hydraulic
Pressure(Bar)		 Max.
Hydraulic
Pressure(Bar)
DTS20D 15 25 25 35 160
DTS30D 15 40 40 35 160


Options:

* Add weapon tongs.

* Left and right arm clamping independent movement.

1900kg Plastic Hydraulic Drum Grabber Forklift Attachment

Applicable Industries

It is widely used in petroleum and chemical industries and other applications that need to deal with standard barrels.

Can be customized according to size

Customized solutions:

Carton Clamp

Block Clamp

Bale Clamp

Roll Clamp

......

all kinds of attachment
