2.5ton Forklift Clamp Attachment Single Double Pallet Handler 1100mm
2.5ton Forklift Clamp Attachment Single Double Pallet Handler 1100mm
Specifications
Brand Name :
Bonafe
Place of Origin :
China
MOQ :
1 Units
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5000 Unit/Units per Year
Delivery Time :
5-8 work days
product category: :
Forklift attachment single double pallet handlers
Place of Origin: :
China
Material: :
Steel
Applicable Industries: :
Manufacturing Plant, Hotels, Garment Shops, Building Material Shops
Frame Width: :
1100mm
Weight: :
514kg
Backrest Height: :
1220mm
Vertical Center of Gravity: :
267mm
Horizontal Center of Gravity: :
221mm
Effective Thickness: :
226mm
Description

Forklift accessories single and double pallet loader 1065 * 80 * 40MM forklift


Features

* Wide field of vision and convenient operation.

* Excellent sliding arm bearing to prolong service life.


Options

* Different fork widths and lengths

* Different installation levels



Parameter
2.5ton Forklift Clamp Attachment Single Double Pallet Handler 1100mm

Capacity@
Load Center
(Kg@mm)		 Model No. Minimum Truck Carriage Width
(mm)		 Frame Width
(mm)		 Opening
Range ITI
ITI (mm)		 Opening
Range OTO
(mm)		 Avg.Pallet Spread Frork
Set Spread		 Fork Size
(mm)		 Backrest Height
H
(mm)		 Vertical
Center of
Gravity
VCG
(mm)		 Weight
(kg)		 Effective
Thickness
ET(mm)		 Horizontal
Center of
Gravity
HCG(mm)
2500@600 FDS25G-A009 914 1100 480-790 810-2210 483 710 1065*80*40 1220 267 514 226 221
2500@600 FDS25G-B009 914 1100 480-790 810-2210 483 710 1065*80*40 1220 272 510 221 216

Remark:

1. Get the actual capacity of the stacker and accessories from the stacker manufacturer

2. Two sets of additional oil circuits are required on the forklift.

3. The side wall is 100mm left and 100mm right


Other size available on request.


Hydraulic Flow&Pressure

Model Min.
Hydraulic
Flow(L/min)		 Rec.
Hydraulic
Flow(L/min)		 Max.
Hydraulic
Flow(L/min)		 Min.
Hydraulic
Pressure(Bar)		 Max.
Hydraulic
Pressure(Bar)
FDS25G 20 40 60 35 160

Options:

Heighten load backrest

Different mounting class



Applicable Industries

Manufacturers, hotels, clothing stores, building materials stores

2.5ton Forklift Clamp Attachment Single Double Pallet Handler 1100mm



Can be customized according to size
Customized solutions:
Carton Clamp
Block Clamp
Bale Clamp
Roll Clamp
......
all kinds of attachment
