24V Electric Pallet Truck EPS Standing Pallet Jack 2 Tonne CBD20
24V Electric Pallet Truck EPS Standing Pallet Jack 2 Tonne CBD20
24V Electric Pallet Truck EPS Standing Pallet Jack 2 Tonne CBD20
24V Electric Pallet Truck EPS Standing Pallet Jack 2 Tonne CBD20
Specifications
Brand Name :
JAC
Model Number :
CBD20（EPS）
Certification :
CE/SGS/ISO 9001/ISO 14001/SGS
Place of Origin :
Hefei, China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
5000
Delivery Time :
8 work days
Rated traction weight :
2000kg
Power :
electric
Battery :
Lead-acid battery
Lowered hength :
85mm
Load centre :
600mm
Wheels type :
PU
Lift :
200mm
Min.Turning radius :
1746mm
Width of forks :
540/685mm
Fork dimensions :
50/185/1150（1220）mm
Battery voltage :
24V
Battery rated capacity :
210Ah
Description

24V Electric Pallet Truck EPS Standing Pallet Jack 2 Tonne CBD20

Characteristics 1.1 Manufacturer Unit JAC
1.2 Model 　 CBD20
1.3 Power unit 　 Electric
1.4 Operation 　 Stand
1.5 Load capacity kg 2000
1.6 Load center distance mm 600
Weights 2.1 Service weight (without battery) kg 810(600)
Wheels/Tyres 3.1 Wheels type 　 PU
3.2 Driving wheel size/number 　 φ250×75/1
3.3 Front wheel size/number 　 φ80×80/4
3.4 Balance wheel size/number 　 φ115×55/2
Dimensions 4.1 Lift mm 200
4.2 Lowered fork height mm 85
4.3 Overall length (Pedal down) mm 1925(2320)
4.4 Overall width mm 808
4.5 Overall fork width mm 540/685
4.6 Fork length mm 1150/1220
4.7 Single fork width mm 185
4.8 Turing radius mm 1746
Performance 5.1 The max driving speed,laden/unladen km/h 5.8/6.0
5.2 Service brake 　 Electromagnetic
Drive 6.1 Drive motor V/kw 24V/1.5kw
6.2 Lift motor V/kw 24V/0.8kw
6.3 Battery voltage V/Ah 24V/210Ah
Others 7.1 Type of drive control 　 DC
7.2 Noise level at operator‘s ear dB(A) 67
7.3 Steering type 　 Electronic steering

24V Electric Pallet Truck EPS Standing Pallet Jack 2 Tonne CBD2024V Electric Pallet Truck EPS Standing Pallet Jack 2 Tonne CBD20


24V Electric Pallet Truck EPS Standing Pallet Jack 2 Tonne CBD20

24V Electric Pallet Truck EPS Standing Pallet Jack 2 Tonne CBD20
