Seamless Rain Gutter Cold Roll Forming Machines , Automatic Metal Roofing Machine
Seamless Rain Gutter Cold Roll Forming Machines , Automatic Metal Roofing Machine
Seamless Rain Gutter Cold Roll Forming Machines , Automatic Metal Roofing Machine
Seamless Rain Gutter Cold Roll Forming Machines , Automatic Metal Roofing Machine
Specifications
Brand Name :
XINGHE
Model Number :
XH-GUTTER
Certification :
CE,ISO,TUV,BV
Place of Origin :
Botou,Hebei Province
MOQ :
1 Set
Price :
7000-15000SUD
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 SETS / MONTH
Delivery Time :
20 Working days
Packaging Details :
Naked and fixed into container
Condition :
New
Type :
Tile Forming Machine
Production Capacity :
8-12m/min
Power(W) :
4+3kw
Voltage :
380v,50hz,3 phrases
Dimension(L*W*D) :
8.5*0.8*1.2m
Weight :
4.5T
Warranty :
One year guarantee
After-sales Service :
Engineers available to service
Machine color: :
Any color as you like
Control system :
Automatic plc control
ODM :
Available
Description

New Design Metal Seamless Rain Gutter Cold Roll Forming Machine

Automatic Galvanized Corrugated Gutter Forming Machine

Processing technique and deployment
Processes: manual decoiler --- feeding table --- Roll forming machine --- PLC system --- Hydraulic system --- Post cut

♦Main Parameters of water gutter cold roll forming equipment:

No. main parameter of gutter roll forming machine
1 Suitable to process Color steel plate, galvanized sheet, aluminum coils and etc.
2 Width of the feeding material According to the profile
3 Rollers station 18 rows
4 Thickness of feeding material 0.3-0.8mm
5 Power 4+4kw
6 Size 8500*800*1500mm
7 Productivity 8-12m/min
8 Diameter of shaft 52mm
9 Weight About 4.8 T
10 Voltage 380V 50Hz 3phases
11 Rolling material Carbon Steel 45#
12 Material of the cutting plate Cr12
13 Wall thickness of main forming machine 16mm steel plate
14 Main structure of the machine 300 H steel

♦The advantage of seamless rain gutter cold roll forming machine

seamless rain gutter cold roll forming machine can bend the roll formed pipe, and let the drainpipe and the bending connect to be the whole.The product after roll forming has long working time than the tranditional ppc pipe, and not aging. It can make the project more integrate, and help to enhance the image of the all project.

seamless rain gutter cold roll forming machine is composed of uncoiler, the feed leading table, the main machine, the formation cutting device, hydraulic system, control system and the product bracket.
♦Machine shows
Seamless Rain Gutter Cold Roll Forming Machines , Automatic Metal Roofing Machine
Seamless Rain Gutter Cold Roll Forming Machines , Automatic Metal Roofing Machine

♦Detailed Images

Seamless Rain Gutter Cold Roll Forming Machines , Automatic Metal Roofing Machine

♦Production Process

Seamless Rain Gutter Cold Roll Forming Machines , Automatic Metal Roofing Machine

♦Packaging & Shipping

Seamless Rain Gutter Cold Roll Forming Machines , Automatic Metal Roofing Machine

Packaging Details: Main machine is nude, the computer control box is packed with wooden frame.

Main machine is nude in the container, the computer control box is

packed with wooden packaging.
Delivery Detail: 20 days
