Galvanised Steel Sheets Corrugation Roof Panel Roll Forming Machine 12 Months Warranty
Galvanised Steel Sheets Corrugation Roof Panel Roll Forming Machine 12 Months Warranty
Galvanised Steel Sheets Corrugation Roof Panel Roll Forming Machine 12 Months Warranty
Galvanised Steel Sheets Corrugation Roof Panel Roll Forming Machine 12 Months Warranty
Specifications
Brand Name :
XINGHE
Model Number :
XH1050
Certification :
BV,SGS, CE,ISO9001
Place of Origin :
Botou,Hebei Province
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 SETS / MONTH
Delivery Time :
30 Working days
Packaging Details :
Naked and fixed into container
Condition :
New
Type :
Tile Forming Machine
Tile type :
Colored Steel / PPGI / Galvanized Steel Coil
Power :
4.0+4.0kw
Voltage :
380V 60HZ or at your requirement
Dimension :
7600*1300*1300mm
Machine Weight :
3.5Tons
Warrenty :
12 months warranty and long-life after-sale service
After-sales Service :
Engineers available to service machinery
Middle plate thickness :
16mm
Control System: :
PLC(imported Brand)
Roller Material: :
45#steel Chrome Plated
Shaft Material: :
5mm Chrome Coated
PLC Automatic Zinc Roofing Roll Forming Machine/Corrugated Roof Sheet Making Machine/ Roof Panel For :
75mm
Cutting Blade Material :
Cr 12 High Grade Steel
Description

1.Working Flow& Layout

Galvanised Steel Sheets Corrugation Roof Panel Roll Forming Machine 12 Months Warranty

2.Supplying components of complete machine

NO.
Description
Quantity (set)
Remark
1
5Tmanual decoiler
1
As one complete part
2
Guiding device
1
3
Pre-cutter
1
4
Forming system
1
5
Transmission system
1
6
Hydraulic guillotine
2
7
Support table
2
8
Hydraulic station
1
9
Control box
1
10
Spare parts and tools
1
As attaching list

3.General parameters

No
Item
Parameter
Note
1
Forming Speed
Max8-15 m/min
Excludes cutting
2
Forming station
Around 16 groups
3
Total Power
About 4.0+4.0 KW
4
Total Weight
About 3500KGS
5
Voltage
380v,60hz,3p

4.Roof sheets

Galvanised Steel Sheets Corrugation Roof Panel Roll Forming Machine 12 Months Warranty

The forming rollers is definitely the critical of high speed tile roofing roll forming machine.
We use CAD to design and style and manufacture the rollers. Right after CNC lathe, the
forming rollers might be harden by vacuum heat procedure and completed the profiles once more. These processes make the greater exact forming rollers ,stay away from the deformation in the course of heat therapy and make sure the rollers preciseness and wear resisting capability.
