Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Specifications
Place of Origin :
China
Brand Name :
Forsentek
Model Number :
FYE
MOQ :
1pc
Packaging Details :
1pc/box
Delivery Time :
3-20 working days
Payment Terms :
T/T,Western Union or Paypal
Supply Ability :
5000pcs/month
Usage :
Torque measurement
Theory :
Strain gauge torque sensor
Output :
Analog
Torque measurement direction :
Clockwise&Counterclockwise
Description

Rotary torque transducer rotating torque measurement

Rotary torque transducer rotating torque measurement
Features

  • Strain gauge technology,slip-ring torque sensor
  • Both clockwise and counterclockwise measurement
  • Rotating speed up to 4000RPM
  • 0-5V,0-10V or 4-20mA output achievable through external amplifier
  • Rotating torque measurement,motor torque measure,engine torque measurement

Rotary torque transducer rotating torque measurement
Dimensions(unit in "mm")
Rotary torque transducer rotating torque measurement
Rotary torque transducer rotating torque measurement
Specifications

Capacity 10NM 20NM 30NM 50NM 100NM
Rated output 1.5mV/V
Excitation 5-15V
Zero balance ±2% R.O.
Nonlinearity ±0.25% R.O.
Hysteresis ±0.25% R.O.
Nonrepeatability ±0.1% R.O.
Creep(30min) ±0.1% R.O.
Safe overload 120% F.S.
Ultimate overload 200% F.S.
Compensated temp. -10...+40oC
Operating temp. -20...+60oC
Temp. shift zero ±0.01% R.O./oC
Temp. shift span ±0.01% R.O./oC
Input resistance 350±30 ohms
Output resistance 350±10 ohms
Insulation resistance >5000M ohms
Ingress protection IP50
Material of element Stainless steel
Cable Ø5.3*3000mm
Wiring code Red--Exc+ Green--Exc- Yellown--Sig+ White--Sig-

Rotary torque measurement sensor torque transducer

Rotary torque transducer rotating torque measurement

Rotary torque transducer rotating torque measurement

Rotary torque transducer rotating torque measurement

Rotary torque transducer rotating torque measurement

Rotary torque transducer rotating torque measurement

Rotary torque transducer rotating torque measurement
