Specifications
Brand Name :
Forsentek
Model Number :
FSH
Place of Origin :
China
MOQ :
1pc
Payment Terms :
T/T,Western Union or Paypal
Supply Ability :
3000pcs/month
Delivery Time :
3~25 working days
Packaging Details :
Carton
Usage :
Belt scale load cell,hopper scales
Theory :
Resistance Sensor
Output :
Analog Sensor
Capacity :
10kg 20kg 30kg 50kg 100kg 200kg 500kg
Description

VPG Celtron HBB beading beam load cell hermetically sealed load cell HBB

The single-ended beam load cell is based on the strain gauge technology. It is available in seven different versions with maximum capacities that range from 10kg to 500kg. The load cell with the characteristic bellows has become a worldwide standard. It is widely employed in low-profile platform scales and conveyor scales,packaging machines for dosing and level measurement as well as in weighing modules that, for instance, are used for tank weighing and hopper weighing applications. The metal bellows protects the load cell against the ingress of moisture enables model FSH to function in harsh environments while maintaining its operating specifications,which makes suitable for both indoor and outdoor weight measurement applications.You may find Forsentek load cell FSH interchangeable with HBM load cell Z6FC3,RICE LAKE load cell RL9018SS,RICE LAKE load cell RLHBB,ZEMIC load cell BM11,Tedea-Huntleigh load cell model 355,VPG Revere load cell 9102, VPG Revere load cell SHBxR,VPG Celtron model HBB,etc..

VPG Celtron HBB beading beam load cell hermetically sealed load cell HBB
Specifications

Rated capacity 10kg 20kg 30kg 50kg 100kg 200kg 500kg
Rated output 2.0±0.002mV/V
Excitation 3-15V
Zero balance ±2% R.O.
Nonlinearity ±0.018% R.O.
Hysteresis ±0.018% R.O.
Nonrepeatability ±0.017% R.O.
Creep(30min) ±0.017% R.O.
Safe overload 150% F.S.
Ultimate overload 200% F.S.
Compensated temperature -10...+40oC
Operating temperature -30...+70oC
Temperature shift zero ±0.02% R.O./10oC
Temperature shift span ±0.02% R.O./10oC
Input resistance 390±30 ohms
Output resistance 356±5 ohms
Insulation resistance >5000M ohms
Ingress protection IP68
Material of element Stainless steel
Cable Ø5.3*3000mm 6-core shielded cable
Wiring code Blue--Exc+ Black--Exc-
Green--Sen+ Grey--Sen-
White--Sig+ Red--Sig-

Stainless steel hermetically sealed load cell 500kg 200kg 100kg 50kg 30kg 20kg 10kg

VPG Celtron HBB beading beam load cell hermetically sealed load cell HBB
A load cell sensor is a transducer that converts mechanical force into electrical signal whose magnitude is proportional to the weight(or force) being applied.The measured load or force causes deformation of the measuring element(elastic body),the bonded strain gauge deforms accordingly which will cause the resistance change of the wheatstone bridge,under constant power supply,the output signal between Sig+ and Sig- will change proportionally,thus the load/force can be measured by measuring the output signal from the load cell.

VPG Celtron HBB beading beam load cell hermetically sealed load cell HBB
