Custom Plastic Injection Mold For Home Appliances And Electrical Products
Custom Plastic Injection Mold For Home Appliances And Electrical Products
Specifications
Brand Name :
Forwa
Model Number :
27
Certification :
ISO9001:2008 and ISO 14001
Place of Origin :
China
MOQ :
1set
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
40 sets/month
Delivery Time :
5weeks
Packaging Details :
wooden case
experience :
17years
mold cavity and core :
1.2767,1.2343,S136 etc
mold base :
1.1730,S50,S55C etc
mold standard :
hasco copy,meusburger copy,DME copy etc
Software :
Pro-E, SolidWorks Etc
Mold Life :
1 Million Shots
Description

Plastic Injection Mold for home Appliances and Electrical Products

Description

Equipment Model Qty Made in
CNC Center FANUC U-T14IFE 2 Japan
YCM FV85A 2 Taiwan
Harford CNC-2150H 2 China
OKUMA 1 Japan
EDM Machine ARD M30E 7 Taiwan
Sodick am30l 3 Japan
AM30L 1 China
Wire EDM Charmilles 240 2 Switzerland
GA64S 1 Taiwan
Grinder JL-614 3 Taiwan
WP-614 5 Taiwan
Miller Topone 3-5# 5 Taiwan
Die Spotting machine NICE NC70-1007 1 China
Die Rolling Machine NICE NCF-5 1 China
CMM Mitutoyo C707 1 Japan
Linear Height TESA Micro-Hite M600 1 Switzerland
Tool Microscope Mitutoyo MF-A1720 5 Japan
Projector CPJ-3015Z 1 Taiwan
Gear Tester OSAKA GTR-4LS 1 Japan
Laser Engraving Machine AOHUA Laser AHL-FB20 1 China

Injection molding machine Fanuc 30 Ton 1 Japan
Fanuc 50 Ton 3 Japan
Taichung 50 Ton 2 Taiwan
Haitian 60 Ton 4 China
Taichung 60 Ton 2 Taiwan
Taichung 100 Ton 2 Taiwan
Taichung 120 Ton 1 Taiwan
Haitian 120 Ton 4 China
Taichuang 180 Ton 1 Taiwan
Haitian 200 Ton 1 China
Taichuang 200 Ton 1 Taiwan
Multitech V55-M 1 Taiwan
Arburg 420C 1 Germany
800T 1

Overmold Tooling Design


The most common problems in overmolded cable assemblies center around overmolding approaches that limit the molding and assembly process parameters such that producing an acceptable range of parts is difficult. This is where the approach to overmold tooling design comes together. It is important to integrate the cable assembly process, tooling design and injection molding process. Too often, these functions are segregated and the end result is parts that do not work. The design of overmold tooling that facilitates interchangeable sections, and therefore modular molds, is often a great help in faster response to molding issues and lower tooling costs overall.

The familiar cry of "the molds don't work" often is the result of incomplete design of the overmold tooling relative to the cable assembly process, and utilizing a customer design that combines components, materials and processes that are inherently incompatible. Just as successful cable assemblies begin with good crimps, successful overmolded parts start with good mechanical stability between the components being molded. Once there is mechanical stability, the opportunity to focus on achieving optimum output from the design can be developed. Here, the combination of cavity design and part loading helps to determine the right configuration. Develop a multifaceted design team with a working knowledge of cable assembly and termination, overmold tooling design and injection molding processes. Approach the tooling equation from a less is better approach, and look at the total cost, including tooling, projected over the life of the part.
