24Ah IP65 Solar Street Light Life 12 Volt Lifepo4 Battery Cycle > 2000 Times
24Ah IP65 Solar Street Light Life 12 Volt Lifepo4 Battery Cycle > 2000 Times
24Ah IP65 Solar Street Light Life 12 Volt Lifepo4 Battery Cycle > 2000 Times
24Ah IP65 Solar Street Light Life 12 Volt Lifepo4 Battery Cycle > 2000 Times
24Ah IP65 Solar Street Light Life 12 Volt Lifepo4 Battery Cycle > 2000 Times
24Ah IP65 Solar Street Light Life 12 Volt Lifepo4 Battery Cycle > 2000 Times
24Ah IP65 Solar Street Light Life 12 Volt Lifepo4 Battery Cycle > 2000 Times
24Ah IP65 Solar Street Light Life 12 Volt Lifepo4 Battery Cycle > 2000 Times
24Ah IP65 Solar Street Light Life 12 Volt Lifepo4 Battery Cycle > 2000 Times
24Ah IP65 Solar Street Light Life 12 Volt Lifepo4 Battery Cycle > 2000 Times
Specifications
Brand Name :
FORZATEC
Model Number :
FT-LFP-12-24
Certification :
CE ROHS
Place of Origin :
CHINA
MOQ :
50 PCS
Payment Terms :
T/T
Supply Ability :
100K PER MONTH
Delivery Time :
15 DAYS UPON ORDER
Packaging Details :
CARTON AND PALLETS
Battery type :
Lifepo4
Nominal voltage :
12.8V
Nominal Capacity :
≥24Ah (Test condition @ 0.3C, 25°C)
Charge cut-off voltage :
14.6V
Discharge cut-off voltage :
10.8V
Self-discharge :
< 3% per month
Battery pack size :
128*70*128mm
Weight :
2.5kg
Description

12V24Ah Lifepo4 Lithium Ion Battery IP65 solar street light Long life cycle:> 2000 times
Product Description
Feature
1. Safety: safest Lithium battery, CE UL approved, built-in PCM/BMS
2. Clean and Green energy, no toxic material contained
3. Long life cycle:> 2000 times, 6-8 times of lead acid battery
4. No memory effect, highly efficient, charge anytime
5. Small size and light weight: 1/2 size& weight of lead acid battery
6. Good performance at high temperature
7. Low self-discharge rate: < 3% monthly

Electrical Characteristics Nominal Voltage 12.8V
Nominal Capacity 24Ah
Energy 300Wh
Internal Resistance ≤10mΩ
Cycle Life >2000 cycles@1C 100% DOD
Months Self Discharge <3%
Efficiency of Charge 100%@0.5C
Efficiency of Discharge 96-99% @1C
Standard Charge Charge Cut-off Voltage 14.6±0.2V
Charge Mode 0.2C to 14.6V, then 14.6V charge current to 0.02C(CC/CV)
Standard Charge Current 4A
Max. Charge Current 20A
Standard Discharge Continuous Current 20A
Max. Pulse Current 40A(10S)
Discharge Cut-off Voltage 10V
Environmental Charge Temperature 0℃ to 45℃(32F to 113F)@60±25% Relative Humidity
Discharge Temperature -20℃ to 60℃(-4F to 140F)@60±25% Relative Humidity
Storage Temperature 0℃ to 40℃(32F to 104F)@60±25% Relative Humidity
Water Dust Resistance IP65
Mechanical Cell&Method 4S
Plastic Case
Dimensions(in./mm.) Customized size
Weight(lbs./kg.) 2.5kg
Terminal M6
Display screen Option
Bluetooth Option

24Ah IP65 Solar Street Light Life 12 Volt Lifepo4 Battery Cycle > 2000 Times
