Electric Start Utility Four Wheeler / 4 Stroke 400cc Quad Bike With Balance Shaft
Electric Start Utility Four Wheeler / 4 Stroke 400cc Quad Bike With Balance Shaft
Electric Start Utility Four Wheeler / 4 Stroke 400cc Quad Bike With Balance Shaft
Electric Start Utility Four Wheeler / 4 Stroke 400cc Quad Bike With Balance Shaft
Electric Start Utility Four Wheeler / 4 Stroke 400cc Quad Bike With Balance Shaft
Electric Start Utility Four Wheeler / 4 Stroke 400cc Quad Bike With Balance Shaft
Electric Start Utility Four Wheeler / 4 Stroke 400cc Quad Bike With Balance Shaft
Electric Start Utility Four Wheeler / 4 Stroke 400cc Quad Bike With Balance Shaft
Specifications
Brand Name :
RONGYAO
Model Number :
utility vehicle atv400-10
Certification :
EC,EEC,DOT,EPA
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T, Western Union,
Supply Ability :
1000 pcs/month
Delivery Time :
Within 20 Days
Packaging Details :
Metal Frame with Carton
Product name :
400cc utility vehicle atv
Transmission :
Automatic CVT with H-L-N-R
Engine oil :
15W-40
COMPRESSION RATIO :
10.5:1
BATTERY :
12V/14AH
MAX.LOAD(kgs/lbs) :
180kg
Description

400cc,4 Stroke,with balance shaft,Water Cooled,Electric Start and Hang Pull

Model:

utility vehicle atv400-10

Product Description:

ENGINE
ENGINE TYPE 4 Stroke,with balance shaft,Water Cooled
MAX.POWER(KW/rpm) 15.2KW @ 7000rpm
MAX.TORQUE(NM/rpm) 28N.M @ 5500rpm
CYLINDER NO. Single Cylinder
BORE STROKE 78mm × 75.2mm
DISPLACEMENT 359.1ml
COMPRESSION RATIO 10.5:1
SPARK PLUG DR8EA
STARTING Electric Start & Hang Pull
IGNITION C.D.I
DRIVETRAIN
FINAL DRIVE SYSTEM Shaft / 4WD & 2WD
TRANSMISSION Automatic CVT with H-L-N-R
MAX.SPEED 82KM/h
SUSPENSION/BRAKES
SHOCK ABSORBER Four-wheel independent suspension
The snow characteristics Four-snow Rubble Tracks Can be choosed
BRAKE FRONT&REAR Hydraulic disc brake
BRAKE DISTANCE 7m @ 30km/h
MISC
BATTERY 12V/14AH
ENGINE OIL 1.5L
FUEL 90# unleaded gasoline
FUEL CAPACITY 19L
MAX.LOAD(kgs/lbs) 180kg
FRONT& REAR TIRE 25×8-12/25×10-12/25
OVERALL 2250×1180×1230
PACKAGE40HQ`(SET) 30pcs
SEAT HEIGHT(mm) 900mm
NET WEIGHT(kgs/lbs) 305kgs

Applications:

1. adult

2. Forest road

3. Riverbed, Stream

4. Mountain Road

5. Beach

6. Farm

7. Pleasure Ground

Terms of transaction:

Our warranty is 1 years. If your vehicle is broken,the spare parts will be sent to you free of charge. This vehicle will be sent to you assembled by sea and you can ride as soon as getting it. The terms of payment is wire transfer,western union or . The delivery time is about 20 days.

Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.

Company Information;

1. All of the ATV Frame is use the 2.5mm seamless steel pipe ligt arc welding,production by our factory workeshop.reliable and stability.

2. All of the ATV engine is come from original engine factory. have not the renovation engine.

3.Each one ATV come out from factory, All must go through rigorous drive testing.To ensure the quality of each ATV.

4.We have one Professional team to do the after-sales service, Provide the solution to solve your worries on the ATV problems.

Warranty time
We supply you 12 months for warranty time, during the warranty time, we supply you free parts!!
