AMEISON 1700-2700MHz 2×9dbi Globe Flat Patch panel MIMO antenna 4G LTE Modem Router antenna
AMEISON 1700-2700MHz 2×9dbi Globe Flat Patch panel MIMO antenna 4G LTE Modem Router antenna
AMEISON 1700-2700MHz 2×9dbi Globe Flat Patch panel MIMO antenna 4G LTE Modem Router antenna
AMEISON 1700-2700MHz 2×9dbi Globe Flat Patch panel MIMO antenna 4G LTE Modem Router antenna
AMEISON 1700-2700MHz 2×9dbi Globe Flat Patch panel MIMO antenna 4G LTE Modem Router antenna
AMEISON 1700-2700MHz 2×9dbi Globe Flat Patch panel MIMO antenna 4G LTE Modem Router antenna
Specifications
Brand Name :
AMEISON
Model Number :
AMXW-1727VH-9
Certification :
ISO 9001: 2008
Place of Origin :
China
MOQ :
100
Price :
EXW Price
Payment Terms :
Paypal, L/C, T/T
Supply Ability :
50,000 Pieces per Month
Delivery Time :
7-25 working days
Packaging Details :
PP bag /inner box/master carton or customized
Frequency range（MHz） :
1700-2700
Polarization :
Vertical and Horizontal
Gain（dBi） :
2×9
VSWR :
≤1.5
Lightning protection :
DC Ground
Input connector type :
2xSMA male or Requested
Description

AMEISON 1700-2700MHz 2×9dbi Globe Flat Patch panel MIMO antenna 4G LTE Modem Router antenna

Feature:

High gain

Full day working

Optimized dimension

Dual polarization

Application:

DCS,PCS,3G,4G,LTE system

Wireless communication and data transmission system

AMXW-1727VH-9

Electrical Specifications
Frequency range(MHz) 1710～2690
Polarization Vertical and Horizontal
Gain(dBi) 2×9
Half-power beam width(°) H:65 V:65
Front-to-back ratio(dB) ≥25
Input Impedance(Ω) 50
VSWR ≤1.5
Isolation between ports ≥28dB
Remote tilt(°) 0
Cross-polar ratio ≥15dB@0º ≥10dB@+/-60º
Sidelobe suppression for first sidelobe above horizon 15 dB
Maximum input power(W) 200
Lightning protection DC Ground
Mechanical Specifications
Input connector type 2-SMA Male
Cable length 30cm or requested
Dimensions-mm (Height/Width/Depth) 225*195*47
Antenna weight (kg) 0.45
Radome material ABS
Radome color White
Operating temperature(°c) -40～60
Rated Wind Velocity(m/s) 60
Mounting hardware(mm) ￠35～￠50
