Automotive Battery Interface Ceramic Fiber Aerogel Felt Flame Retardancy Automotive Interior & Exterior Trim
Automotive Battery Interface Ceramic Fiber Aerogel Felt Flame Retardancy Automotive Interior & Exterior Trim
Automotive Battery Interface Ceramic Fiber Aerogel Felt Flame Retardancy Automotive Interior & Exterior Trim
Automotive Battery Interface Ceramic Fiber Aerogel Felt Flame Retardancy Automotive Interior & Exterior Trim
Automotive Battery Interface Ceramic Fiber Aerogel Felt Flame Retardancy Automotive Interior & Exterior Trim
Automotive Battery Interface Ceramic Fiber Aerogel Felt Flame Retardancy Automotive Interior & Exterior Trim
Specifications
Brand Name :
FQ
Model Number :
Aerogels 01
Certification :
IATF16949
Place of Origin :
China
MOQ :
Customized
Price :
Fuzhou Fuqiang Precision Co.,Ltd.
Payment Terms :
L/C, T/T, D/P
Supply Ability :
1000pcs/day
Delivery Time :
1000 pcs/ days
Packaging Details :
pp bag+Cartons
Material :
Aerogels
Application :
Solar System,EV,Power Bank,E-bike,home use/solar system/energy store
Type :
LiFePO4 Battery Management System(Battery BMS/PCM) 30S 150A,li ion battery BMS
Board thickness :
1.6mm,0.005"-0.250",0.8mm,0.6-0.8mm
Size :
803*512*422,680*400*237.5mm,342*173*212mm,60*64*21mm
Description

Battery Thermal Management System Aerogel Insulation Ceramic Fiber Aerogel Felt flame retardancy

Main Features

Aerogels have the characteristics of low thermal conductivity, good thermal insulation effect and non-combustible. Compared with traditional insulation materials, it only needs 1/5-1/3 thickness to achieve the same insulation effect. It not only saves more space for the power battery but also has the characteristics of a heat preservation effect and a more stable temperature. Therefore, the application in new energy vehicles can better realize the temperature control and electronic control management of the battery and improve the performance, it can play the role of heat insulation and fire prevention, and buy more time for users and passengers to escape the scene and extinguish the fire.

Automotive Battery Interface Ceramic Fiber Aerogel Felt Flame Retardancy Automotive Interior & Exterior Trim

Specification

The main performance parameters are shown in Table

Product model Pysheild BP-PAN
thickness 1~10mm
Wide 1400±100mm(Customized)
color Black
Maximum operating temperature 800℃(Anaerobic)
density 200±20kg/m3
Thermal conductivity ≤0.025W/m*K@25℃ GB/T 10295-2008
≤0.030W/m*K@100℃ GB/T 10294-2008
≤0.036W/m*K@300℃
≤0.072W/m*K@500℃
Combustion rating Grade A GB/T 8624-2012
V0 UL94-2013
Water repellency ＞98% GB/T10299-2011
Biosecurity Meets biosafety requirements RoHs/REACH/ELV
Shear strength ＞0.3MPa ASTM C273
Thermal insulation effect 1mm:Min≥385℃；2mm:Min≥440℃
3mm:Min≥495℃；4mm:Min≥520℃
Application areas It has the functions of heat insulation, buffering, flame retardancy, thermal runaway protection and other functions of new energy passenger vehicle cells and modules.

Typical Applications

The functions of heat insulation, buffering, flame retardancy, thermal runaway protection and other functions of new energy passenger vehicle cells and modules
