Android box receiver V8 Angel Online dvb support IPTV wireless newcam cccam internet sharing

Specifications

Brand Name :

Freesat

Model Number :

V8 Angel

Place of Origin :

China

MOQ :

1pcs

Payment Terms :

T/T, Western Union, MoneyGram

Supply Ability :

10000pcs per month

Delivery Time :

2-3work days

Packaging Details :

10pcs/Ctn

Android box receiver :

V8 Angel Online dvb support IPTV wireless newcam cccam internet sharing

1 :

Android 4.4 TV BOX+DVB-S/S2,DVB-T/T2,Cable.（only support DVB-C J.83-AC， Don't support DVB-C J.83-B)

2 :

Android Box/OTT+IPTV/Live Streaming/Online.

3 :

XBMC Addons pre-installed.(KODI14.2)

4 :

3D/H265 movies supported.

5 :

Amlogic S805 1GBRAM +8GBROM

6 :

2.4G wifi, wireless internet and Btuetooth 4.0

7 :

Support and Cccam,Newcam.

Description

Android box receiver V8 Angel Online dvb support IPTV wireless newcam cccam internet sharing

I. Highlight:

1, Android 4.4 TV BOX+DVB-S/S2,DVB-T/T2,Cable.(only support DVB-C J.83-AC, Don't support DVB-C J.83-B)

2, Android Box/OTT+IPTV/Live Streaming/Online.　　

3, XBMC Addons pre-installed.(KODI14.2)　　

4, 3D/H265 movies supported.　　

5, Amlogic S805 1GBRAM +8GBROM　　

6, 2.4G wifi, wireless internet and Btuetooth 4.0　　

7, Support and Cccam,Newcam.　　

8, Technical support website : www.freesat.cn/forum/　　

Note: We reserve the right to change the design and OEM/ODM supported

II. Picture & Packaging

	Product Size (MM)	1559025(LWH)	Packaging	20pcs/ctn
	Gift Box size(mm)	23517370	Carton size(mm)	485355358
	Panel display	Yes	Display Color	white light
	USB	2 x USB 2.0 High Speed Host
	TF Card	support
	IR	Exit IR for 38KHz
	Output Interface	LNB IN1,RF IN1, ETHERNET,DV OUT, AV, S/PDIF, Power supply
	HDMI	HDMI(up to 1080P) output
III. Main Features:
	Standard	Full HD 1080P IPTV+DVB-S2/T2/C Box
	Video game	Live Streaming ,VoD and Game content for free.
	IPTV	Stalker Middleware for adding IPTV server
	Video Decode	HDMI for HD and CVBS for SD outputs
	Signal display	RF signal strength and signal quality display
	Channels number	Manage up to 10,000 TV and Radio channels
	USB display	2 X USB support HDD multimedia play DivX,TS,MKV,TP,AVI,VOB,DAT,MPG,11MPEG,MOV,AAC,MP3,WMA,JPG,BMP,JPEG,PNG
	OSD	True colors on screen display friendly user menu
	Language	Multi languages, English by default
	PAL/NTSC	Automatic PAL/NTSC conversion
	EPG	EPG up to 7 days
	Channel Search	Channel search in automatic, manual and network search
	Channel Edit	Various channel editing function(favorite,move,lock,skip,delete,rename,find,sort)
	Parental Ctrl	Parental control for channels
	Easy Menu	Plug and Play installation, with an easy to use Menu System
	Power off memory	Channel information save in memory after power off
	PVR	PVR via plug-in USB HDD
	Software upgrade	Software upgrade through USB or TF card and OTA
	Subtitle	Full multi-language DVB subtitling and audio track support
	Teletext	Teletext via OSD & VBI
	Ethernet	Support RMII interface, Internet Sharing
IV.Electric Performance
1.Memory Size:
	Flash Memory	8GB NAND Flash Memory
	DDR3 Memory	1GB 433MHz DDR3 SDRAM Memory
2.DVB-S2 Part
	Connector	1*IEC 169-24 female 75Ω for input
	Demod standard	DVB-S2(EN302 307)
	Demodulation	QPSK, 8PKS, 16APKS, 32APKS for DVB-S2
	Input Frequency Range	950MHZ-2150MHZ
	Input Signal LEVEL	-80/-20dBM
	DiSEqC Protocols	DiSEqC 1.0, 1.1, 1.2, 2.0 USALS Compatible
	Symbol Rate	10Ms/S ˜31Ms/S
	Active Ant Power	13/18V DC @ 450mA MAX,Overload Protection
	De-multiplexer	MPEG2 ISO/IEC 13818-1
3.DVB-T2 Part
	Connector	1*IEC 169-24 female 75Ω for input
	Input Frequency Range	104˜862MHz (VHF/UHF)
	Input LEVEL	-15- -75dBm
	Demod standard	DVB-T2(EN300 744) and (EN302 755)
	Demodulation	QPSK, 16QAM, 64QAM, 256QAM for DVB-T2
	FFT Mode	2K, 8K for DVB-T2 1K, 2K, 4K, 8K, 16K, 32K, 32K ext for DVB-T2
	FEC Code Rate	1/2, 2/3, 3/4, 5/6, 7/8 for DVB-T2 1/2, 3/5, 2/3, 3/4, 4/5, 5/6 for DVB-T2
	Guard Interval	1/4, 1/8, 1/16, 1/32 for DVB-T2 1/4, 5/32, 1/8, 5/64, 1/16, 1/32, 1/64, 1/128 for DVB-T2
	Band Width	6MHz ,7MHz,8MHz
	De-multiplexer	MPEG2 ISO/IEC 13818-1
	Active Ant Power	5V DC @ 100mA MAX,Overload Protection
4.DVB-C Part
	Connector	1*IEC 169-24 female 75Ω for input
	Standard	ITU J.83 Annex A,C, Annex B in option
	Input Frequency Range	47˜862MHz
	Input LEVEL	43˜ 73dBuV for 64QAM, 47˜ 77dBuV for 256QAM
	Symbol Rate	1˜7MBaud with step of 1kBauds
	Constellation	16/32/64/128/256QAM
	Band Width	8MHz in Annex A and C 6MHz in Annex B in option
	De-multiplexer	MPEG2 ISO/IEC 13818-1
	Active Ant Power	5V DC @ 100mA MAX,Overload Protection
5.Video Decode
	Video Decode	High Definition MPEG4 AVC/H.264 HP@L4.1,MPEG-2 MP@HL/ML
	Aspect Ratio	Auto, 16:9 Pillar box, 4:3 Pan & Scan, 4:3 Letter Box
6.Audio Decode
	Audio Decode	MPEG1 layer I, MPEG1 layer II, MPEG1 layer III, MPEG2 AAC, MPEG4 HE-AAC
	Sound Mode	LEFT/RIGHT/STEREO/MONO
	Sampling Frequency	32KHz, 44.1KHz, 48KHz
7.Subtitle & Teletext
	Subtitle	DVB and IPTV Subtitle
	Teletext	EBU TELETEXT
8.Menu Function
	Channel Search	Automatic search based on LCN or NIT
		Manual search based on Frequency and channel number
	Channel -Management	Up to 10,000 channels edition,delete,move,lock,rename;8 favorite ch groups
	EPG	7 days
	Language	English, other languages in option
	Software Update	loader through USB or TF card and OTA
	Security	Menu lock, Parental lock, PIN lock
9.USB Decode
	PVR Option	Play/Stop/Record/Pause/Forward/Back, Scheduled Recording using
	Profiles	3.x, 4.0, 5.0, 6.0 Home Theater & HD profiles
	Media Format	MPEG2, TS, AVI, MKV, ASF, Quick, DivX,FLV, VC-1,DivX 3.X ˜ 6.X,AVI,VOB,MOV,MKV,JPEG,BMP,PNG,Motion JPEG,Flash 3
	Connector	USB 2.0 supporting external hard disk of 250-500GB
	File system	FAT32
	USB	PVR with USB HDD, Time shifting with USB HDD
10.Environment
	Power Supply	DC 12V/2.0A
	Power Consumption	12W in operation , <1W auto Standby Green Power Mode
	Temperature	Operation 0˜+45℃; Storage -10˜+60℃
	Humidity	20˜90%, non-condensed
IIV.Packing
	Android TV BOX	*1
	HDMI Cable	*1
	Charger	*1
	AV Cable	*1
	Remote Control	*1
