Electric Heating Industrial Vacuum Food Freeze Dryer 55kw 100kg/H
Electric Heating Industrial Vacuum Food Freeze Dryer 55kw 100kg/H
Specifications
Brand Name :
ZHIYIN
Model Number :
FDM-100
Place of Origin :
China
MOQ :
1set
Price :
USD/Negotiate price/Set
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1set/Month/Set
Packaging Details :
FCL transport package
Name :
Vacuum freeze drying machine
Function :
Food Vegetable Fruit Dehydrator
Product Type :
Vacuum Freeze Dryer
Heating Method :
Electric Heating
Effective drying surface area :
100m²
Dimension :
5500*2000*3310mm
Power :
55kw
Description
freeze drying machine industrial vacuum food freeze dryer for fruits vegetables
The main technical parameters of the equipment
Project
parameter
Model
GFD-100m²
Quantity
1 set
Effective drying surface area
100m²
Heating method
Steam, radiant heating
Cold trap form
One-time catching and flushing
Maximum processing volume per batch
3m³/tank/time

Feature of freeze drying machine

1.Our freeze drying machine is used in the field of optimized freezing and drying process.

2.The frozen and dried products have the high value, hence, the design of the freezing drying is in terms of safety to the greatest extent. The humanity design applied in the freeze drying machine ensures the safety of the user and environment .

3.The mature design technology is put into the freeze drying machine which is produced with the high quality material and component accepted in the world widely. At the same time, the advanced high-tech process is utilized in the freeze drying machine.

4.Our freeze drying machine design and manufacture Under FDA&cGMP Standard.

Please contact us about how to place an order:
Contact Person: Mrs. Lisa
Job Title: Manager
Business Phone: 086 15249674563
WhatsApp: 086 15249674563
WeChat: 086 15249674563
Skype: 086 15249674563
Email: Sale@frenchfriesline.com/Lisa@frenchfriesline.com
Working principle of freeze dry:
The vacuum freezing and drying machine is a drying method which can sublime the moisture in hydrous materials from solid state to gas state, under low temperature freezing and vacuum condition, after the materials are subjected to the pre-treatment, so as to remove the moisture and preserve the materials.

Parameter of freeze drying machine

Conditions of use
project
parameter
Working temperature of heating plate
Room temperature～120ºC
Cold trap refrigerant evaporation temperature
-30ºC～-45ºC
Working pressure of tank
20Pa～133Pa
Operating parameters
Vacuum reaches 10Pa～133Pa (no load)
15～30min
Single tank static vacuum degree (pressure)
15Pa
Maximum water capacity of single tank cold trap (calculated on ice)
100kg/h
Income index
Standard loading amount
100kg/batch
Maximum loading
130kg/batch
Drying time (the water content is related to the material)
10-20 hours
Medium requirements
Refrigerant (closed cycle)
R404A
Heating medium in heating system (closed loop)
Distilled or deionized water
Air cooler defrosting water (inlet water temperature ≤40ºC, circulating)
Softened water or tap water (circulation)
Cooling water (inlet water temperature ≤32ºC, circulating)
Softened water or tap water (circulation)
Washing water for drying tank, material truck and material pan.
Softened water or tap water

Application of our freeze dryer:
Vacuum freeze-drying technology is applied to process food material to make freeze dried food. The freeze dryer is used in all conceivable kinds of agricultural products with top drying quality. Fruits: durian, strawberry, mango, apricot, kiwifruit, pineapple, lemon, raspberry, avocado, banana etc. Vegetables: broccoli, parsley, mushroom, bean, scallion, asparagus, onion, celery, carrot, tomato, pepper etc. Other food: beef, coffee, colostrums, herbal, flower, tea, honey, sea food and all kinds of pets food.

Service:

1) Professional advice and rich experience help to choose machine.

2) Lifelong maintainance and considerate technical support

3) Technicians can be sent to abroad to install.

4) Any problem before or after delivery, you could find and talk with us anytime.

5) Video / CD of test running and installation, Maunal book, tool box sent with machine.

FAQ:
1.Q:What is your warranty of machine ?

Answer: 1 years warranty , lifetime maintenance.

2.:How to install the machine?

Answer:we will supply install manual to you.Also,We can assign our engineers to go to your country.

3.Q:About the machine voltage or power of machine ?

Answer:The voltage can be customized according to your country standard.

Packing

Size it depends
Weight depends
Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
