PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity
PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity
PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity
PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity
PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity
PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity
PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity
PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity
Specifications
Brand Name :
Friend
Model Number :
PC / SWP series
Certification :
CE,SGS,TUV
Place of Origin :
Jiangsu Province,China
MOQ :
one set
Price :
negotiation
Payment Terms :
T/T, L/C
Supply Ability :
76 sets per month
Delivery Time :
15 worker days
Packaging Details :
wooden package
Blade material :
SKD-11
Capacity :
100-500kg/h
power :
7.5-30kw
Fixed blade :
2 pieces
Rotary blade :
5-21 pieces
Shaft diameter :
240-370mm
Application :
Film,Pipe,Tray,etc.
Screen hole diameter :
12mm or customized
Warranty :
one year
Description

Plastic PC / SWP series waste pvc pipe crusher machine prices

Feature:

Crusher for plastic pipe blades material is SKD-11

Blade base and blade can be disassembly, it is easy to clean and maintenance .

Push material feeding system adopt hydraulic ways, it's running very stably .

Main axis is drived by gearbox , it's running very stably ,low noise and strong power .

Rotating blade adopt the V design , it can decrease the noise and energy consumption .

Crusher for plastic pipe is controlled by PLC system,blade can rotate in opposite direction,also can automatic closed if something unexpected happened,which is advanced and safety service.

Main technical parameters:

Model Crushing capacity
kg/hr		 Power
Kw/Hp		 Into size
mm		 Stationary
Cutter		 Rotary Cutter Machine Size
L*W*H		 Weight
Kgs
fld-30 90-120 2.2/3.0 180*160 2 9 500*430*900 250
fld
-50		 100-160 4.0/5.0 290*220 2 15 850*620*1050 350
fld
-100		 150-400 7.5/10.0 400*250 2 21 970*800*1340 740
fld
-150		 300-600 11.0/15.0 460*300 2 24 1200*1100*1350 1000
fld
-200		 500-800 15.0/20.0 515*330 2 37 1320*1155*1700 1300
fld
-300		 700-1000 22.0/30.0 550*440 2 30 1320*1210*1800 1700
fld
-500		 1500-1800 37.0/50.0 720*500 2 39 2850*1430*2180 3200

PC600 crusher

PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity

PC600 crusher control box

PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity

SWP400 Crusher

PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity

SWP400 Crusher blade

PC / SWP Series Strong Plastic Crusher Machine 100-500kg/H Capacity

Please feel free to contact me!
