0.5A-5A solar charge controller with constant-current driver for solar LED garden light
0.5A-5A solar charge controller with constant-current driver for solar LED garden light
Specifications
Place of Origin :
Made in China
Brand Name :
FRW
Certification :
Made in China
Model Number :
Made in China
MOQ :
1-UP
Price :
Made in China
Packaging Details :
CARTON
Delivery Time :
according to quantity
Payment Terms :
T/T, L/C
Supply Ability :
Made in China
Description

small solar charge controller

available: 0.5A 2A 4A 5A:

Solar Lamp Controller Intergrated LED Constant Current Driver

Main Fetures:

The running-parameters can be set via Infrared remote control

12V rechargeable battery support(only 12V,not support 24V)

Three Timing adjustment

Three-Stage LED Brightness Dimming:100%->50%->30%

(can be manual set)

output current can be adjusted

The DAY-NIGHT switch-point can be adjusted ,range: 0-3..9V

Overcharge and overdischarge protection for battery

Reverse connection protection for solar panel

Reverse connection protection for battery(but connect carefully)

Load short-circuit protection (but connect carefully)

SM-05A

3.6V ,6V,7.2V and 12V optional

Max charging current:<500mA(<=5W solar module)

Max Constant Current Output:<350mA

Four-Stage LED Brightness Dimming

SM-2AN-0A35

12V rechargeable battery support

Max charging current:2A(<=35W solar module)

Loads mode 1#: switch output: max 2A

Loads mode 2#: reduction voltage constant-current output: 50-350mA

SM-4AN-0A7

12V rechargeable battery support

Max charging current:4A (<=70W solar module)

Loads mode 1#: switch output: max 5A

Loads mode 2#: reduction voltage constant-current output: 100-700mA

SM-4AN-1A5

12V rechargeable battery support

Max charging current:4A (<=70W solar module)

Loads mode 1#: switch output: max 5A

Loads mode 2#: reduction voltage constant-current output: 200-1400mA

Fourth-Stage Dimming Explain

The Fourth-Stage Dimming is core feature of SM-0A5.

In most case,We want more energy-saving at mid-night or late-night,because there are no one. The Controller provide Fourth-Stage light mode,every stage brightness of LED and timer can be set by IR Parameters Setting Device [SM-IR08]. Default the First-Stage brightness is 100%, Second-Stage brightness is 50%, Third-Stage brightness is 30%.Fourth-Stage brightness is 50%.By using Foruth-Stage Dimming you can reduce power consumption up to 50%!

Other note :The Fourth-Stage is Early-Morning Light .

Brightness(mA)

100%

50%

30% Timer(Hour)

First Second Thrid Fourth
