Our in-house engineers support both clients and sales teams. Their primary function is to ensure data integrity and find the best possible design solutions available for you.

Our customized stock management service is a vital part of our High Frequency PCB solutions. We will ensure your regular and planned course of production never runs out of PCBs, whether it’s at different locations within one facility or multiple locations in a supply network.

‘Buffered stock’ focuses on stabilising variations in supply, demand, production, or lead time. We’ll set up a ‘just-in-time delivery’ system to minimise excess inventory, thereby reducing wastage and expense, and you can rest assured materials will be in the place of manufacture or assembly at the appropriate time.

Advantage:

Specialized in high frequency PCB, double-sided multi-layer PCB manufacturer,

maximum processing layers 28 layers, the company has a full range of domestic and imported

high frequency material(Rogers ROGERS, TACONIC series, high frequency microwave PTFE circuit

boards, Teflon Teflon, PTFE circuit boards, dielectric constant ranging from 2.2 10.6), to provide quality and efficient products for you

RF power sensor equipment with wide dynamic range and high measurement accuracy, package size Similar to typical power heads. The device can perform true power measurement and can also measure automatic test. Use the path loss. Calibration numbers, including linearity and temperature corrections, are stored directly on the equipment. Some models can be triggered by external hardware, or they can be based on external trigger sources. The source of the signal is triggered by the software. In the Scope and Slot modes, software extrudes can be used to measure WiMAX and LTE bursts. Burst waveforms and multislot waveforms such as GSM and EDGE. This equipment is very suitable for mobile applications, or added to automated testing applications. Releasing the rack space of Baogui does not affect the performance.

An RF power sensor using a capacitor to measure RF signal power includes a substrate preferably formed of a semiconductor, such as silicon, or a dielectric material, and a fixed component fixed on the substrate constitutes a signal line and a ground line for transmitting a radio frequency signal, and spans The signal line is connected to the bridge between the ground lines, wherein the bridge is subjected to an external driving force, and the external driving force induces a capacitance between the bridge and the signal line. Correspondingly, the RF signal power is measured by the capacitance between the signal line and the bridge. The RF power sensor facilitates matching and reduces insertion loss. Because it is based on the characteristic impedance of the transmission line, it can be used in a very wide frequency band. According to the design of the bridge, high power can also be measured.

Get a Fast Rogers,Taconic RF PCB Quote with Custom Circuit Boards

We are confident that once you have experienced the Custom Circuit Board's difference, you will continue to use us for all of your future quickturn PCB business. We look forward to quoting your PCBs and earning your business.

Reliable Rogers PCB prototyping services with the highest quality.

For Rogers PCB prototyping, we are able to manufacture low volume single and double-sided PCBs to complex multilayer PCBs with blind and buried vias at affordable prices.

From an electronic hobbyists to an established fortune 500 company, we are able to handle all of your Rogers and other high frequency PCB prototyping requirements in-house. Unlike PCB brokers, we don't outsource your work to other companies and you deal directly with us, Rogers PCB manufacturer. We have a state-of-the-art manufacturing facility located in Shenzhen with over 5000 square feet of fabrication machinery.
